Top rated products
PCBA BOARD FOR AC-825IP
SKU:
AC-825IP-PCBA
- Up to 58 doors, 100,000 users, and 500,000 history log entries (FIFO) per ACU
- Onboard TCP/IP networking to the AxTraxNG or AxTraxPro server, bidirectional push communication for enhanced data transmission speed and reliability
- Supports SIA Open Supervised Device Protocol (OSDP V2) including OSDP Secured Channel Protocol to let the AC-825IP controller connect to any peripheral device that supports OSDP1
- AES 256-bit symmetric data encryption to the AxTraxPro server to make sure the data is secure
- 4 auxiliary inputs and 2 auxiliary outputs
- One onboard expansion slot and an additional 12 expansion boards via OSDP V2 including secure channel protocol (R/S/D/P-805)
- R-805 – 16 outputs
- S-805 – 16 inputs
- D-805 – 4-door expansion
- P-805 – 16 inputs and 8 outputs
- AC-825IP can be installed in a ME-1515 metal enclosure
- Holds 2 expansion boards or an AC-825IP board
- C14 power plug and supports Pull-Safe cable locks for secured wiring
- Built-in tamper and light bar
- DIN rail mounting option for space saving with no additional enclosure needed
- Power management board indicates battery and power status
PCBA BOARD FOR AC-825IP
SKU:
AC-825IP-U
- Up to 58 doors, 100,000 users, and 500,000 history log entries (FIFO) per ACU
- Onboard TCP/IP networking to the AxTraxNG or AxTraxPro server, bidirectional push communication for enhanced data transmission speed and reliability
- Supports SIA Open Supervised Device Protocol (OSDP V2) including OSDP Secured Channel Protocol to let the AC-825IP controller connect to any peripheral device that supports OSDP1
- AES 256-bit symmetric data encryption to the AxTraxPro server to make sure the data is secure
- 4 auxiliary inputs and 2 auxiliary outputs
- One onboard expansion slot and an additional 12 expansion boards via OSDP V2 including secure channel protocol (R/S/D/P-805)
- R-805 – 16 outputs
- S-805 – 16 inputs
- D-805 – 4-door expansion
- P-805 – 16 inputs and 8 outputs
- AC-825IP can be installed in a ME-1515 metal enclosure
- Holds 2 expansion boards or an AC-825IP board
- C14 power plug and supports Pull-Safe cable locks for secured wiring
- Built-in tamper and light bar
- DIN rail mounting option for space saving with no additional enclosure needed
- Power management board indicates battery and power status
PIEZO MULL. PIN ONLY SECURED CTRL AND 26 BIT RDR
SKU:
AYC-E55
- Supports 4- to 8-digit PIN credentials
- Smooth, attractive design, for all-weather indoor and outdoor operation
- Large, highly visible piezoelectric keypad
- 2 tri-colored LEDs and an integral sounder for programming and operation
- User-friendly menu system based on keypad, LED, and sounder indicators
- Optical back tamper detection output
- Default operation as a multi-format reader Automatically recognizes Rosslare’s PS-x25T intelligent power supply family converting it into a 500-user standalone controller with secure relays
Piezoelectric Backlit Proximity & PIN Reader – Convertible
SKU:
AYC-T65 (N/B)
- Supports 4- to 8-Digit PIN credentials and 125 KHz EM type RFID cards and tags
- Smooth, attractive design, with all-weather indoor and outdoor operation
- Large, high-visibility unique illuminated piezoelectric keypad
- Optical back tamper detection output
- 2 tri-colored LEDs and an integral sounder for programming and operation
- User-friendly menu system based on keypad, LED, and sounder indicators
- Automatically recognizes a connection to PS-x25T intelligent power supplies and converts into a 500-user standalone controller with secure relays
- Available in two models: AYC T65B in black color and AYC-T65N in natural color
PIN/PROX GANG BOX PLASTIC SECURED CONTROLLER AND 26 BIT READER
SKU:
AYC-F64
- Supports 4- to 8-Digit PIN credentials and 125 KHz EM type RFID cards and tags
- Smooth, attractive design, with all-weather indoor and outdoor operation
- Large, highly-visible RED backlit keypad
- 2 tri-colored LEDs and an integral sounder for programming and operation
- User friendly menu, based on keypad, LED, and sounder indicators
- Back and cover optical tamper detection and output
- Default operation as a multi-format reader (Wiegand 26-Bit/Clock & Data)
- Automatically recognizes Rosslare’s PS-x25T intelligent power supply family converting it into a 500-user standalone controller with secure relays
PLASTIC MULL. PIN ONLY SECURED CTRL AND 26 BIT RDR BACKLIT
SKU:
AYC-G54
- Supports 4- to 8-Digit PIN credentials
- Smooth, attractive design, with all-weather indoor and outdoor operation
- Large, high-visibility RED backlit keypad
- 2 tri-colored LEDs and an integral sounder for programming and operation
- User-friendly menu, based on keypad, LED and sounder indicators
- Back and cover optical tamper detection and output
- Automatically recognizes Rosslare’s PS-x25T intelligent power supply family converting it into a 500-user standalone controller with secure relays
PLASTIC MULL. PIN/PROX SECURED CTRL AND 26 BIT RDR BACKLIT
SKU:
AYC-G64
- Supports 4- to 8-digit PIN credentials and 125 kHz EM type RFID cards and tags
- Smooth, attractive design, with all-weather indoor and outdoor operation
- Large, highly-visible RED backlit keypad
- 2 tri-colored LEDs and an integral sounder for programming and operation
- User friendly menu, based on keypad, LED and sounder indicators
- Back and cover optical tamper detection and output
- Default operation as a multi-format reader (Wiegand 26-Bit/Clock & Data)
- Automatically recognizes Rosslare’s PS-x25T intelligent power supply family converting it into a 500-user standalone controller with secure relays
Power Management Enclosure with built in Secure Relay I/O Module
SKU:
PS-C25TB
- Relay for secure door operation using Rosslare AYC series of convertible controllers
- Global input voltage – 110 VAC to 240 VAC 50/60Hz auto select.
- Delivers two isolated 14.5VDC @2 Amp
- Universal C14 power plug for standard power cable connection (order option).
- Rosslare PowerLock C13 socket – power cable can be secured using a locking mechanism and cannot be pulled out of the socket
Professional Fingerprint Biometrics Reader
SKU:
AY-B9250BT
- Advanced optical sensor with fingerprint liveness check with algorithms to prevent spoofing.
- Capacity of 20,000 templates 1:N and support for 1:1 Matching, and encrypted memory, Built-in color LCD, camera for transaction capture, 4 touch buttons
- High performance CPU and memory for high speed validation (searches 4000 1:N in less than 1 second)
- Built-in TCP/IP, RS-485, and Wiegand 26- or 34-bit output connectivity
- Non-volatile event log of up to 100,000 entries
- IP65 rated for indoor and outdoor use
- Support for Rosslare BLE-IDTM smartphone credentials (Both iOS and Android)
- Built-in tamper and buzzer, output relay for controlling a local device
- Modern design that blends into almost any architectural challenge
Professional Fingerprint Biometrics with EM-RFID and Rosslare BLE-ID Reader
SKU:
AY-B9120BT
- Advanced optical sensor with fingerprint liveness check with algorithms to prevent spoofing
- Capacity of 20,000 templates 1:N and support for 1:1 Matching, and encrypted memory
- Built-in output relay for controlling a local device
- High performance CPU and memory for high speed validation (searches 4000 1:N in less than 1 second)
- Built-in TCP/IP, RS-485, and Wiegand output connectivity
- Non-volatile event log of up to 100,000 entries
- IP65 rated for indoor and outdoor use
- Support for Rosslare BLE-IDTM smartphone credentials (both iOS and Android)
- Wide thermal operating range (-20°C to 60°C)
- Built-in tamper and buzzer
- Modern design that blends into almost any architectural challenge
Professional Fingerprint Biometrics with MIFARE RFID and Rosslare BLE-ID Reader
SKU:
AY-B9150BT
- Advanced optical sensor with fingerprint liveness check with algorithms to prevent spoofing
- Capacity of 20,000 templates 1:N and support for 1:1 Matching, and encrypted memory
- Built-in output relay for controlling a local device
- High performance CPU and memory for high speed validation (searches 4000 1:N in less than 1 second)
- Built-in TCP/IP, RS-485, and Wiegand output connectivity
- Non-volatile event log of up to 100,000 entries
- IP65 rated for indoor and outdoor use
- Support for Rosslare BLE-IDTM smartphone credentials (Both iOS and Android)
- Wide thermal operating range (-20°C to 60°C)
- Built-in tamper and buzzer
- Modern design that blends into almost any architectural challenge
PROGRAM READER VANDAL PROX US GANG
SKU:
AYC-Q65
- Supports 4- to 8-digit PIN credentials and 125 kHz EM type RFID cards and tags
- Smooth, attractive design, with all-weather indoor and outdoor operation
- Large, highly-visible piezoelectric keypad
- 2 tri-colored LEDs and an integral sounder for programming and operation
- User-friendly menu, based on LED and sounder indicators
- Back and cover optical tamper detection and output.
- Multi-format reader (Wiegand 26-Bit/Clock & Data/Card & PIN)
- Automatically recognizes Rosslare’s PS-x25T intelligent power supply family converting it into a 500-user standalone controller with secure relays
