LPR Cameras

Showing all 3 results

SKU: PKC2640@Z28-P

Lens Size	2.8-12mm
Sensor	1/1.8-inch 4MP CMOS
IR Range	Up to 50 m
Protection	IK10,IP67
Camera Resolutions	4 MP
Minimum illumination	0.001lux (F1.4)
Image collection format	26881520@30 (default),26881520@25
Frame rate	30 (default),25,22,20,18,16,15,12.5,10,8,6,5,4,3,2,1
Shutter	Auto/Manual,range: 1/30 to 1/100000s
ROI	Supports up to 8 regions
BNC	PAL,NTSC
Video OSD	Supports 8 overlay areas and allows contents including date,time,date&time,zoom ratio,custom contents
Application scenario	≤ 30km/h for entrances and exits,≤ 80km/h for regular roads; Supports simultaneous application to road and entry/exit scenes without switching
Video Compression	H.264 (default),H.265
Illumination	Built-in integrated illumination module,including 4 warm light LEDs,50m illumination distance,automatic on/off control
Compatible Integration	ONVIF (Profile S,Profile G,Profile T),SDK,API
Edge Storage	Supports ANR with a Micro SD card,up to 256GB
Weight	2.1kg
Power supply	DC12V + 25% – 10% Max. power consumption: 20W Supports PoE (802.3at,class 4)
Dimensions (L×W×H)	406mm x 126mm x 130mm
Operating environment	-40℃ to 60℃,≤90% RH
Heater	N/A
EMC	CE-EMC (EN 55032:2015+A11:2020+A1:2020,EN 61000-3-3:2013+A1:2019+A2:2021,EN IEC 61000-3-2:2019+A1:2021,EN 50130-4:2011+A1:2014) FCC(FCC CFR 47 part15 B,ANSI C63.4 2014)
Safety	EN IEC 62368-1:2020+A11:2020 UL (UL 62368-1,2nd Ed.,Issue Date: 2014-12-01)
Environment	CE-RoHS (2011/65/EU;(EU)2015/863);WEEE (2012/19/EU)
Camera Style	Bullet

SKU: PKC2640@Z80-IR-P

Lens Size	8 ~ 32mm
Sensor	1/1.8″ CMOS
IR Range	Up to 50 m
Protection	IK10,IP67
Camera Resolutions	4 MP
FOV	Horizontal FOV: 42.4° to 15.9°,Vertical FOV: 23.9° to 9.8°,Diagonal FOV: 52.5° to 17.8°
Min. Illumination	0.002lux (F1.7)
Image collection format	26881520@30 (default),26881520@25
Shutter	Auto/Manual,range: 1/30 to 1/100000s
Frame rate	30 (default),25,22,20,18,16,15,12.5,10,8,6,5,4,3,2,1
Video compression	H.264 (default),H.265
ROI	Supports up to 8 regions
Video OSD	Supports 8 overlay areas and allows contents including date,time,date&time,zoom ratio,custom contents
Application scenario	≤ 80km/h for regular roads; Camera with the focal length of 8 to 32mm can be used for regular roads
Vehicle detection mode	Supports video detection
License plate number recognition	Supports recognition of license plates with numbers and letters by default
Edge Storage	Supports ANR with a Micro SD card,up to 256GB
Bracket	3-axis mounting bracket
Compatible Integration	ONVIF (Profile S,Profile G,Profile T),SDK,API
Interface Network	1×10M/100M RJ45
Storage interface	1 × Micro SD card slot
Power supply	DC12V + 25% – 10% Max. power consumption: 20W Supports PoE (802.3at,class 4)
Dimensions (L×W×H)	406mm x 126mm x 130mm
Weight	2.1kg
Operating environment	-40℃ to 60℃,≤90% RH
Heater	N/A
Camera Style	Bullet

SKU: PKC2640@Z80-P

Lens Size	8 ~ 32mm
Sensor	1/1.8″ CMOS
IR Range	Up to 50 m
Protection	IK10,IP67
Camera Resolutions	4 MP
FOV	Horizontal FOV: 42.4° to 15.9°,Vertical FOV: 23.9° to 9.8°,Diagonal FOV: 52.5° to 17.8°
Min. Illumination	0.002lux (F1.7)
Image collection format	26881520@30 (default),26881520@25
Shutter	Auto/Manual,range: 1/30 to 1/100000s
Frame rate	30 (default),25,22,20,18,16,15,12.5,10,8,6,5,4,3,2,1
Video compression	H.264 (default),H.265
ROI	Supports up to 8 regions
Video OSD	Supports 8 overlay areas and allows contents including date,time,date&time,zoom ratio,custom contents
Application scenario	≤ 80km/h for regular roads; Camera with the focal length of 8 to 32mm can be used for regular roads
Vehicle detection mode	Supports video detection
License plate number recognition	Supports recognition of license plates with numbers and letters by default
Edge Storage	Supports ANR with a Micro SD card,up to 256GB
Bracket	3-axis mounting bracket
Compatible Integration	ONVIF (Profile S,Profile G,Profile T),SDK,API
Interface Network	1×10M/100M RJ45
Storage interface	1 × Micro SD card slot
Power supply	DC12V + 25% – 10% Max. power consumption: 20W Supports PoE (802.3at,class 4)
Dimensions (L×W×H)	406mm x 126mm x 130mm
Weight	2.1kg
Operating environment	-40℃ to 60℃,≤90% RH
Heater	N/A
Camera Style	Bullet
