NETWORK PTZS CAMERA

Product Overview

The NP112-ID PTZ dome camera offers advanced monitoring capabilities for indoor environments. Equipped with a 1/2.8" progressive scan CMOS sensor, it delivers Full HD 1080p resolution at 30 frames per second. Digital zoom up to 16× allows detailed observation across wide areas. Intelligent 3D positioning ensures smooth and accurate tracking of subjects. Power-off memory restores PTZ and lens status after interruptions. The camera adheres to multiple interoperability standards including ONVIF, CGI, and PSIA, ensuring compatibility with diverse platforms. Its IP66-rated housing and IK08 impact protection provide durable, reliable performance. Various mounting options make it suitable for in-ceiling deployment in commercial and enterprise settings.

Key Features

• Full HD 1080p resolution with high-performance imaging
• ±0.1° PTZ preset accuracy for precise positioning
• 16× digital zoom for close-up detail observation
• 3D intelligent positioning for smooth target tracking
• Power-off memory retains PTZ and lens settings after reboot
• Wide interoperability: ONVIF, CGI, PSIA standards
• Robust indoor protection: IP66 and IK08 impact resistance

Key Specifications

• Image Sensor: 1/2.8" Progressive Scan CMOS
• Effective Pixels: 1920(H) × 1080(V)
• Shutter Time: 1/1–1/10,000 s
• Power: 12V DC / PoE (802.3af), max. 18 W
• Protection Rating: IP66, IK08

Product Overview

Designed for outdoor surveillance, the NP112-IR/25X provides robust monitoring capabilities with Full HD 1080p resolution at 30 fps. Its 1/2.8” progressive scan CMOS sensor ensures excellent image clarity, while WDR, HLC, BLC, 3D DNR, and defog functions enhance performance in diverse environments. Optical zoom up to 25× and digital zoom 16× allow precise observation at a distance. The camera supports endless 360° pan and -15° to 90° tilt with adjustable speeds, and up to 300 presets for versatile monitoring patterns. Edge recording via microSD up to 128 GB adds storage flexibility. IP66-rated protection ensures reliable operation in outdoor conditions. This dome camera is ideal for large outdoor spaces requiring detailed and responsive surveillance.

Key Features

• Full HD 1080p resolution with advanced low-light performance
• 25× optical zoom & 16× digital zoom for distant object recognition
• Up to 100 m IR range for night-time clarity
• Digital WDR, 3D DNR, HLC/BLC, defog, and regional exposure support
• Flexible pan/tilt: 360° endless pan, -15°~90° tilt with auto-flip
• Multiple monitoring modes: preset, patrol, pattern, scan, and panorama
• Privacy masking and ROI support for sensitive area protection

Key Specifications

• Image Sensor: 1/2.8" Progressive Scan CMOS
• Min. Illumination: Color: 0.005 Lux, B/W: 0.001 Lux, 0 Lux with IR
• Pan/Tilt Speed: Manual: 0.1°–80°/s, Preset: 80°/s
• Video Compression: H.265+/H.265/H.264/MJPEG
• Protection Rating: IP66, IK10

Product Overview

NP224-IR/25X combines ultra-high resolution imaging with robust PTZ capabilities to deliver complete coverage for expansive monitoring environments. The 1/2.8″ Progressive Scan CMOS sensor delivers crisp 4 MP resolution, capturing every detail with precision. Its 25× optical zoom and 16× digital zoom allow close-up inspection of distant subjects, while advanced WDR, HLC, BLC, 3D DNR, defog, regional exposure, and regional focus maintain image quality under challenging lighting. Night-time security is supported with IR illumination up to 150 m. Multi-stream H.265+/H.265 encoding ensures efficient video transmission and storage. PoE and 24 VAC power options enhance installation flexibility. The camera’s metal construction ensures durability for demanding outdoor environments. Part of the Pro Series, it meets professional security standards.

Key Features

• Ultra-High Definition 4 MP Imaging: Capture detailed visuals with a 1/2.8″ Progressive Scan CMOS sensor, ensuring sharp 1920 × 1080 imagery for critical security applications.
• Powerful PTZ Control: 25× optical and 16× digital zoom provide precise monitoring across expansive zones, allowing detailed surveillance of distant subjects.
• Advanced Image Enhancement: Integrated WDR, HLC, BLC, 3D DNR, defog, and regional focus optimize image quality in diverse lighting conditions.
• Extended Night Vision: IR illumination reaches up to 150 m, delivering reliable night-time surveillance in complete darkness.
• Efficient Video Compression: H.265+/H.265 support reduces bandwidth and storage requirements without compromising image quality.
• Flexible Power Options: Supports 24 VAC and PoE (802.3at) for versatile deployment in both new and existing network infrastructures.
• Durable Construction: Metal housing ensures robust protection for long-term outdoor operation.

Key Specifications

• 1/2.8" Progressive Scan CMOS
• High quality imaging with 4 MP resolution
• Excellent low-light performance
• 25× optical zoom and 16× digital zoom provide close up views over expansive areas
• WDR, HLC, BLC, 3D DNR, defog, regional exposure, regional focus
• Expansive night view with up to 150 m IR distance
• 24 VAC & PoE (802.3at)
• Efficient H.265+/H.265 compression technology

Product Overview

NP302A-IR/30X provides robust surveillance capabilities for outdoor and industrial settings with extreme temperature requirements. Its 1/2.8″ progressive scan CMOS sensor captures sharp 2 MP resolution imagery, ensuring critical details are not missed. The 30× optical zoom paired with 16× digital zoom allows precise monitoring of distant targets, while digital WDR, 3D DNR, and smart IR maintain clarity under strong backlight or low-light conditions. True day/night functionality provides continuous monitoring, and smart tracking enables automatic following of moving objects. Additional intelligent features include ROI encoding and defog for enhanced image quality. The camera supports 3 video streams for multi-platform viewing and is compatible with both 24 VAC and High-PoE power supplies. Ideal for environments where temperature extremes and demanding operational conditions are present.

Key Features

• High-Definition 2 MP Imaging: 1/2.8″ progressive scan CMOS delivers crisp 1920 × 1080 resolution for accurate surveillance.
• Extended PTZ Coverage: 30× optical and 16× digital zoom provide detailed views over long distances.
• Intelligent Tracking & ROI: Smart tracking automatically follows moving objects; ROI encoding optimizes bandwidth for areas of interest.
• Superior Low-Light Performance: True day/night operation with 3D DNR and digital WDR ensures clear imaging in variable lighting conditions.
• Long-Range Night Vision: Smart IR enables up to 120 m IR coverage for expansive night monitoring.
• Defog Capability: Enhances image clarity in foggy or adverse weather conditions.
• Flexible Power Options: Supports 24 VAC and High-PoE, allowing versatile deployment in various infrastructures.

Key Specifications

• 1/2.8" progressive scan CMOS
• 30x optical zoom, 16x digital zoom
• Smart tracking, defog, ROI encoding, HLC
• Smart IR, 393.7' IR distance 3-streams
• True day/night, 3D DNR, digital WDR
• 3D intelligent positioning
• 24 VAC / High-PoE power supply

Product Overview

NP312-OD/25X provides dependable PTZ surveillance performance with advanced imaging technologies and flexible network integration. Built around a 1/2.8″ progressive scan CMOS sensor, the camera captures clear Full HD video at up to 1920 × 1080 resolution and 60 frames per second for smooth real-time monitoring. The integrated 25× optical zoom lens allows operators to observe distant details with precision while maintaining image clarity. Image enhancement technologies including 120 dB WDR, HLC, BLC, 3D DNR, Defog, and Electronic Image Stabilization (EIS) optimize image quality under challenging lighting and environmental conditions. Regional exposure and regional focus further improve image accuracy for important monitoring zones. Efficient H.265+/H.265 compression helps reduce bandwidth consumption and storage requirements without compromising video quality. With PoE+ and 24 VAC power support, the camera can be deployed flexibly across various surveillance infrastructures. Its IP66 and IK10 rated protection ensures stable performance in demanding outdoor environments.

Key Features

• Full HD 1080p Imaging at 60fps: Captures smooth and detailed video with a 1/2.8″ progressive scan CMOS sensor delivering up to 1920 × 1080 resolution.
• Long-Range Optical Zoom Monitoring: 25× optical zoom combined with 16× digital zoom enables detailed observation across large surveillance areas.
• Advanced Image Enhancement Suite: 120 dB WDR, HLC, BLC, 3D DNR, and Defog technologies improve clarity in challenging lighting and weather conditions.
• Electronic Image Stabilization: EIS reduces image shake to maintain stable and clear video during PTZ movement.
• Optimized Regional Imaging: Regional exposure and regional focus help prioritize important areas within the scene for better visibility.
• Efficient Video Compression: Supports H.265+ and H.265 encoding to significantly reduce bandwidth and storage usage.
• Flexible Network Deployment: Compatible with both PoE+ (802.3at) and 24 VAC power supplies for versatile installation.

Key Specifications

• 1/2.8" progressive scan CMOS
• Up to 1920 × 1080@60fps resolution
• Min. illumination: Color: 0.005 Lux @(F1.6, AGC ON) B/W: 0.001 Lux @(F1.6, AGC ON)
• 25× optical zoom, 16× digital zoom
• WDR, HLC, BLC, 3D DNR, Defog, EIS, Regional Exposure, Regional Focus
• 24 VAC & PoE+ (802.3 at, class4)
• Support H.265+/H.265 video compression

Product Overview

NP354-IR/SL 32X combines high-resolution imaging, intelligent analytics, and powerful PTZ capabilities to meet the demands of professional security environments. Equipped with a 1/1.8″ progressive scan CMOS sensor, it captures sharp 4 MP video at up to 2560 × 1440 resolution. Powered-by-DarkFighter technology ensures excellent image quality even in extremely low-light conditions. The 25× optical zoom lens enables detailed monitoring of distant targets while maintaining image clarity. Integrated deep learning algorithms provide accurate classification of human and vehicle targets, significantly reducing false alarms. The camera also supports simultaneous face capture for up to five faces in a scene, improving situational awareness. IR illumination extends to 200 m, allowing effective night-time surveillance over wide areas. In addition, an audio and visual alarm with flashing white light and audible warning can be triggered during security events, helping deter intrusions. Designed with IP66 and IK10 protection, the camera delivers reliable performance in demanding outdoor environments.

Key Features

• High-Resolution 4 MP Imaging: Utilizes a 1/1.8″ progressive scan CMOS sensor to deliver detailed video at up to 2560 × 1440 resolution.
• Powered-by-DarkFighter Low-Light Technology: Ensures exceptional image clarity in extremely low-light environments.
• Intelligent Target Classification: Deep learning algorithms accurately distinguish human and vehicle targets, reducing false alarms.
• Long-Range PTZ Monitoring:32× optical zoom and 16× digital zoom allow operators to observe distant objects with precision.
• Extended IR Night Vision: High-performance IR illumination reaches up to 200 m for reliable night-time surveillance.
• Active Deterrence Alarm: Integrated flashing white light and audible warning can be triggered by security events.
• Multi-Face Capture Capability: Detects and captures up to five faces simultaneously for improved situational awareness.

Key Specifications

• Image Sensor: 1/1.8″ Progressive Scan CMOS
• Max Resolution: 2560 × 1440 (4 MP)
• Optical Zoom: 32× optical zoom, 16× digital zoom
• IR Distance: Up to 200 m
• Protection Level: IP66, IK10
