Tri-Guard 2.0 Series

High quality image with 4 MP, 1/2.7" CMOS sensor 4 MP (2688 × 1520)@30/25 (default) fps; 4 MP (2560 × 1440)@30/25 fps; 3 MP (2304 × 1296)@30/25 fps; 1080P (1920 × 1080)@30/25 fps Ultra 265, H.265, H.264, MJPEG Intelligent perimeter protection, including cross line, intrusion, enter area, leave area detection Intelligent intrusion prevention system based on target classification significantly reduces false alarms caused by leaves, birds, and lights, accurately focusing on humans, vehicles, and non-motor vehicles Intelligent people flow counting and crowd density monitoring Smart intrusion prevention with color retrieval ASM (auto scene match) 130 dB true WDR technology enables clear image in strong light scene Supports red and blue warning light Supports 9:16 corridor mode Alarm I/O: 1/1, audio I/O: 1/1, built-in mic and speaker Smart IR, up to 40 m (131.2 ft) IR distance MicroSD, up to 512 GB IP67 protection

High quality image with 4 MP, 1/2.7" CMOS sensor 4 MP (2688 × 1520)@30/25 (default) fps; 4 MP (2560 × 1440)@30/25 fps; 3 MP (2304 × 1296)@30/25 fps; 1080P (1920 × 1080)@30/25 fps Ultra 265, H.265, H.264, MJPEG Intelligent perimeter protection, including cross line, intrusion, enter area, leave area detection Intelligent intrusion prevention system based on target classification significantly reduces false alarms caused by leaves, birds, and lights, accurately focusing on humans, vehicles, and non-motor vehicles Intelligent people flow counting and crowd density monitoring Smart intrusion prevention with color retrieval ASM (auto scene match) 130 dB true WDR technology enables clear image in strong light scene Supports red and blue warning light Supports 9:16 corridor mode Alarm I/O: 1/1, audio I/O: 1/1, built-in mic and speaker Smart IR, up to 40 m (131.2 ft) IR distance MicroSD, up to 512 GB IP67 protection

High quality image with 5 MP, 1/2.7" CMOS sensor 5 MP (2880 × 1620)@30/25 (default) fps; 4 MP (2560 × 1440)@30/25 fps; 3 MP (2304 × 1296)@30/25 fps; 1080P (1920 × 1080)@30/25 fps Ultra 265, H.265, H.264, MJPEG Intelligent perimeter protection, including cross line, intrusion, enter area, leave area detection Intelligent intrusion prevention system based on target classification significantly reduces false alarms caused by leaves, birds, and lights, accurately focusing on humans, vehicles, and non-motor vehicles Intelligent people flow counting and crowd density monitoring Smart intrusion prevention with color retrieval ASM (auto scene match) 130 dB true WDR technology enables clear image in strong light scene Supports red and blue warning light Supports 9:16 corridor mode Alarm I/O: 1/1, audio I/O: 1/1, built-in mic and speaker Smart IR, up to 40 m (131.2 ft) IR distance MicroSD, up to 512 GB IP67 protection

High quality image with 5 MP, 1/2.7" CMOS sensor 5 MP (2880 × 1620)@30/25 (default) fps; 4 MP (2560 × 1440)@30/25 fps; 3 MP (2304 × 1296)@30/25 fps; 1080P (1920 × 1080)@30/25 fps Ultra 265, H.265, H.264, MJPEG Intelligent perimeter protection, including cross line, intrusion, enter area, leave area detection Intelligent intrusion prevention system based on target classification significantly reduces false alarms caused by leaves, birds, and lights, accurately focusing on humans, vehicles, and non-motor vehicles Intelligent people flow counting and crowd density monitoring Smart intrusion prevention with color retrieval ASM (auto scene match) 130 dB true WDR technology enables clear image in strong light scene Supports red and blue warning light Supports 9:16 corridor mode Alarm I/O: 1/1, audio I/O: 1/1, built-in mic and speaker Smart IR, up to 40 m (131.2 ft) IR distance MicroSD, up to 512 GB IP67 protection

High quality image with 8 MP, 1/2.8" CMOS sensor 8 MP (3840 × 2160)@30/25 (default) fps; 5 MP (3072 × 1728)@30/25 fps; 4 MP (2560 × 1440)@30/25 fps; 1080P (1920 × 1080)@30/25 fps Ultra 265, H.265, H.264, MJPEG Intelligent perimeter protection, including cross line, intrusion, enter area, leave area detection Intelligent intrusion prevention system based on target classification significantly reduces false alarms caused by leaves, birds, and lights, accurately focusing on humans, vehicles, and non-motor vehicles Intelligent people flow counting and crowd density monitoring Smart intrusion prevention with color retrieval ASM (auto scene match) 130 dB true WDR technology enables clear image in strong light scene Supports red and blue warning light Supports 9:16 corridor mode Alarm I/O: 1/1, audio I/O: 1/1, built-in mic and speaker Smart IR, up to 40 m (131.2 ft) IR distance MicroSD, up to 512 GB IP67 protection

High quality image with 8 MP, 1/2.8" CMOS sensor 8 MP (3840 × 2160)@30/25 (default) fps; 5 MP (3072 × 1728)@30/25 fps; 4 MP (2560 × 1440)@30/25 fps; 1080P (1920 × 1080)@30/25 fps Ultra 265, H.265, H.264, MJPEG Intelligent perimeter protection, including cross line, intrusion, enter area, leave area detection Intelligent intrusion prevention system based on target classification significantly reduces false alarms caused by leaves, birds, and lights, accurately focusing on humans, vehicles, and non-motor vehicles Intelligent people flow counting and crowd density monitoring Smart intrusion prevention with color retrieval ASM (auto scene match) 130 dB true WDR technology enables clear image in strong light scene Supports red and blue warning light Supports 9:16 corridor mode Alarm I/O: 1/1, audio I/O: 1/1, built-in mic and speaker Smart IR, up to 40 m (131.2 ft) IR distance MicroSD, up to 512 GB IP67 protection
