- Support Ultra 265/H.265/H.264 video formats
- 4/8/16-channel input
- Plug & Play with 4/8 independent PoE network interfaces
- Support 1-ch HDMI, 1-ch VGA, HDMI at up to 4K(3840×2160) resolution
- HDMI and VGA simultaneous output
- Up to 4K resolution recording
- Support cloud upgrade
| Channels |
8 Channel |
|---|---|
| SATA |
1 SATA Interfaces |
| PoE |
8 |
| Decoding Format |
Ultra 265 ,H.265 ,H.264 |
| Decoding Capability |
1 x 4K@30 ,4 x 5MP@25 ,4 x 4MP@25 ,4 x 3MP@25 ,6 x 1080P@30 ,8 x 720P@30 |
| Decoding Capability Description |
The resolution of each channel cannot exceed 4000 pixels in length and 3000 pixels in width |
| Incoming Bandwidth |
64 Mbps |
| Outgoing Bandwidth |
48 Mbps |
| Remote Users |
128 |
| Recording Resolution |
8 MP/6 MP/5 MP/4 MP/3 MP/1080P/960P/720P/D1/2CIF/CIF |
| Capacity |
Up to 10 TB for each HDD (The maximum HDD capacity varies with environment temperature and hard disk size) |
| Network Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet Interfac |
| USB |
Rear panel: 2 × USB2.0 |
| Power Supply |
DC 52 V/1.8 A |
| PoE Interface |
8 RJ45 10 M/100 M self-adaptive Ethernet Interface |
| Max Power |
Max 30 W for single port ,Max 75 W in total |
| Supported Standard |
IEEE 802.3at ,IEEE 802.3af |
| Power Consumption (without HDD) |
≤ 9W |
| Weight (without HDD) |
≤ 0.8Kg (1.76lb) |
| Dimensions |
270mm × 205mm × 46mm (10.6"×8.1"×1.8") |
| Certification |
CE; FCC; UL; RoHS; WEEE |
| CE |
EN 55032 ,EN 61000-3-3 ,EN IEC 61000-3-2 ,EN 55035 |
| FCC |
Part15 Subpart B |
