- Support Ultra 265/H.265/H.264 video formats
- 64/128-channel input
- Support 2-ch HDMI, 2-ch VGA, HDMI1 at up to 8K(7680×4320) resolution, HDMI2 at up to 4K(3840×2160) resolution
- VGA1 and HDMI1 simultaneous output, VGA2 and HDMI2 simultaneous output. VGA1/HDMI1 and VGA2/HDMI2 independent output
- Up to 32 Megapixels resolution recording
- Redundant power supply optional
- Support HDD hot swap with RAID 0, 1, 5, 6, 10, 50, 60 storage scheme configurable
- Support 12V power output
- ANR technology to enhance the storage reliability when the network is disconnected
- Support cloud upgrade
- Support N+1 Hot spare
| Channel |
128 Channel |
|---|---|
| SATA |
16 SATA Interfaces |
| PoE |
N/A |
| Decoding Format |
Ultra 265 ,H.265 ,H.264 |
| Decoding Capability |
H264 : 2 x 32MP@30 ,4 x 16MP@30 ,6 x 12MP@30 ,9 x 4K@30 ,14 x 5MP@30 ,18 x 4MP@30 ,24 x 3MP@30 ,36 x 1080P@30 ,72 x 720P@30 ,128 x D1 H265 : 3 x 32MP@30 ,6 x 16MP@30 ,8 x 12MP@30 ,12 x 4K@30 ,19 x 5MP@30 ,24 x 4MP@30 ,32 x 3MP@30 ,48 x 1080P@30 ,96 x 720P@30 ,128 x D1 |
| Decoding Capability Description |
The resolution of each channel cannot exceed 8640 pixels in length or width ,For VGA/HDMI independent output ,the VGA live video is output by default. To output the highest resolution video from the HDMI port ,please clear the VGA video on the preview page. |
| Incoming Bandwidth |
640Mbps |
| Outgoing Bandwidth |
640Mbps |
| Remote Users |
128 |
| Recording Resolution |
32 MP/16 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080P/960P/720P/D1/2CIF/CIF |
| Capacity |
Up to 16 TB for each HDD (The maximum HDD capacity varies with environment temperature) |
| Network Interface |
2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet Interface |
| USB |
Front panel: 2 × USB2.0 ,Rear panel: 2 × USB3.0 |
| Power Supply |
AC 100 to 240 V |
| RS485 |
1 |
| RS232 |
1 |
| Alarm In |
16-ch |
| Power Consumption (without HDD) |
≤ 50W |
| Weight (without HDD) |
≤ 6.5Kg (14.3lb) |
| Dimensions |
482mm × 533mm × 131mm (19.0"×21.0"×5.1") |
| Certification |
CE; FCC; UL; RoHS; WEEE |
| CE |
EN 55032 ,EN 61000-3-3 ,EN IEC 61000-3-2 ,EN 55035 |
| FCC |
Part15 Subpart B |
