2 Megapixel 1080P HD-CVI IR Mini Dome Camera - Image 1
Click to enlarge

2 Megapixel 1080P HD-CVI IR Mini Dome Camera

WINIC

2 Megapixel 1080P HD-CVI IR Mini Dome Camera

Add to wishlist
Add to compare
SKU: HAC-HDBW2220E-3.6 Categories: ,
  • 1/2.8″ 2.4Megapixel CMOS
  • 25/30fps@1080P, 25/30/50/60fps@720P
  • High speed, long distance real-time transmission
  • HD and SD switchable
  • OSD Menu, control over coaxial cable
  • DWDR, Day/Night(ICR), AWB, AGC, BLC, 3DNR
  • 3.6mm fixed lens (6mm, 8mm optional)
  • Max. IR LEDs length 30m, Smart IR
  • IP67, IK10, DC12V
Angle of View

H: 88º(55º/38.6º)
Day & Night

Auto(ICR) / Color / B/W
Dimensions

Φ109.9mm×81.0mm
Effective Pixels

1984(H)×1225(V)
Electronic Shutter Speed

1/3s~1/100

,

000s
Focal Length

3.6mm
Frame Rate

25/30/50/60fps@720P; 25/30fps@1080P
Image Sensor

1/2.8" 2.4Megapixel CMOS
Protection

IK10

,

IP67
Material

Metal
Max. IR LEDs Length

30m

,

Smart IR
Min. Illumination

0.05Lux/F1.8

,

0Lux IR on
Lens Mount

M12
Noise Reduction

2D/3D
OSD Menu

Support
Power Consumption

Max 3.5W
Power Supply

DC12V±20%
Synchronization

Internal
Transmission Distance

Over 500m via 75-3 coaxial cable
Video Output

1-channel BNC HDCVI high definition video output/ CVBS standard definition video output (Can switch)
Weight

0.3kg
Working Environment

-30°C~+60°C / Less than 95%RH (no condensation)
Camera Resolutions

2 MP
Camera Style

Dome
