3‐Axis Adjustment	Pan: 0° to 355° , tilt: 0° to 70°
Alarm Trigger	Motion detection , video tampering , network disconnected , IP address conflict , illegal login , HDD full , HDD error
API	ONVIF (PROFILE S , PROFILE G) , ISAPI
Audio Bit Rate	64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
Audio Compression	G.711/G.722.1/G.726/MP2L2/PCM
Audio Sampling Rate	8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Auto iris	No
Behavior Analysis	Line crossing detection , intrusion detection
Channel Bandwidth	20/40MHz
Client	CMS , Guarding vision
Communication Interface	1 RJ45 10M/100M self-adaptive Ethernet port
Day & Night	Day/Night/Auto/Schedule/Triggered by alarm in (-A)
Digital Noise Reduction	3D DNR
Dimensions	Camera: Φ 111 × 82.4 mm (Φ 4.4" × 3.2") With package: 135× 135 × 110 mm (5.3" × 5.3" × 4.3")
Electronic Shutter Speed	1/3 s to 1/100 , 000 s
Environment Noise Filtering	Yes
Focal Length	2.8mm
Focus Control	Fixed
FOV	2.8 mm: horizontal FOV: 115° , vertical FOV: 62° , diagonal FOV: 136°
Frequency Range	2.4 GHz to 2.4835 GHz
General Function	Anti-flicker , heartbeat , mirror , password protection , privacy mask , watermark , IP address filter
H.264 Type	Baseline Profile/Main Profile/High Profile
H.264+	Main stream supports
H.265 Type	Main Profile
H.265+	Main stream supports
Image Enhancement	BLC/3D DNR
Image Sensor	1/2.8" Progressive Scan CMOS
Image Settings	Rotate mode , saturation , brightness , contrast , sharpness adjustable by client software or web browser
IR Range	Up to 20 m
Lens Mount	M12
Main Stream	50Hz: 25fps (1920 × 1080 , 1280 × 960 , 1280 × 720) 60Hz: 30fps (1920 × 1080 , 1280 × 960 , 1280 × 720)
Material	Front cover: plastic , base: metal
Max Aperture	F2.0
Max. Resolution	1920 × 1080
Min. Illumination	Color: 0.01 Lux @(F1.2 , AGC ON) , 0.028Lux @(F2.0 , AGC ON); B/W: 0.001 Lux @(F1.2 , AGC ON) , 0.0028 Lux @(F2.0 , AGC ON)
Network Protocols	TCP/IP , ICMP , HTTP , HTTPS , FTP , DHCP , DNS , DDNS , RTP , RTSP , RTCP , PPPoE , NTP , UPnP™ , SMTP , SNMP , IGMP , 802.1X , QoS , IPv6 , Bonjour
Network Storage	Support built-in micro SD/SDHC/SDXC card (128G) , local storage and NAS (NFS , SMB/CIFS) , ANR
On-Board Storage	Built-in micro SD/SDHC/SDXC slot , up to 128 GB
Operating Conditions	-30 °C to +60 °C (-22 °F to +140 °F) , humidity 95% or less (non-condensing)
Power Consumption	PoE: (802.3af , 36V-57V) , 0.2 A to 0.1 A , max. 6.5W 12 VDC , 0.4 A , max. 5W
Power Supply	12 VDC ± 25% , PoE (802.3af , class 3)
Protection	IP67
Protocols (Wireless)	802.11b: DQPSK , DBPSK , CCK 802.11g/n: 64-QAM , 16-QAM , QPSK , BPSK
Region of Interest	1 fixed region for main stream
Reset Button	Yes
Security (Wireless)	64/128-bit WEP , WPA/WPA2 , WPA-PSK/WPA2-PSK , WPS
Simultaneous Live View	Up to 6 channels
Slow Shutter	Yes
Sub‐Stream	50Hz: 25fps (704 × 576 , 640 × 480 , 352 × 288 , 320 × 240) 60Hz: 30fps (704 × 480 , 640 × 480 , 352 × 240 , 320 × 240)
Transfer Rates	11b: 11Mbps , 11g: 54Mbps , 11n: 65Mbps
User/Host Level	Up to 32 users 3 levels: Administrator , Operator and User
Video Bit Rate	32 Kbps to 8 Mbps
Video Compression	Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG
Wavelength	850nm
Web Browser	IE8+ , Chrome 31.0-44 , Firefox 30.0-51 , Safari 8.0+
Weight	Camera: approx. 400 g (0.9 lb.) With package: approx. 500 g (1.1 lb.)
Wide Dynamic Range	120 dB
Wireless Range	50 m
Wireless Standards	IEEE 802.11b/g/n
Camera Style	Dome
Lens Type	Fixed Lens

2 MP IR Fixed Dome Network Camera
