2-READER EXPANSION MODULE FOR AC-225X-B CONTROL PANEL

ROSSLARE

2-READER EXPANSION MODULE FOR AC-225X-B CONTROL PANEL

Add to wishlist
Add to compare
SKU: MD-D02B Category:
  • Additional two proximity readers or keypads
  • Four relay outputs and four supervised inputs to the access control panel
  • Wiegand or Clock-and-Data transmission keypad or biometric reader compatibility
  • LED status feedback for 12 V power and relay activation
  • Cost effective and modular installation
  • Input and output configurability using Rosslare’s AxTraxNG or AxTraxPro Access
Input Voltage

12 VDC from host controller
Input Current (not including devices)

Standby: 30 mA Maximum: 135 mA
Number of Reader Ports

2
Number of Inputs

4
Output Relays

4 x 5 A with N.O., N.C. and COM contacts Form-C Relays
Inputs Voltage

5 VDC maximum voltage
Reader Output Voltage

12 VDC
Maximum Reader Current

300 mA
LED Control Output

Open collector, active low
Tamper Input

5 VDC maximum voltage
Supported Formats

Various, please refer to the AxTraxNG User Guide or the AxTraxPro User Guide
Power LED

Active when connected to a power source
Output LEDs

Four LEDs, each output LED is active when an output relay is activated and N.O. to COM contacts are shorted
Dimensions

100 x 75.9 x 32.5 mm (3.9 x 3.0 x 1.3 in.)
Weight

98.2 g (0.2 lb)
PRODUCT WARRANTY

2-year limited product warranty
