2Mp 25X H.265 Full HD Network IR PTZ Surface Mount Dome Camera
2Mp 25X H.265 Full HD Network IR PTZ Surface Mount Dome Camera
- 1/2.8″ progressive scan CMOS
- Up to 1920 × 1080 resolution
- Min. illumination:
- Color: 0.005 Lux @(F1.6, AGC ON)
- B/W: 0.001 Lux @(F1.6, AGC ON)
- 0 Lux with IR
- 25× optical zoom, 16× digital zoom
- 120 dB WDR, 3D DNR, HLC, BLC
- Up to 50 m IR distance
- 12 VDC & PoE+ (802.3 at, class4)
- Support H.265+/H.265 video compression
| Alarm Interface |
2-ch alarm input and 2-ch alarm input |
|---|---|
| Alarm Trigger |
Alarm actions ,such as Memory Card Video Record ,Trigger Recording ,Notify Surveillance Center ,Upload to FTP/Memory Card/NAS ,Send Email ,etc. |
| Aperture range |
F1.6 to F3.5 |
| API |
Open-ended ,support ONVIF ,ISAPI ,support SDK and Third-Party Management Platform |
| Audio Interface |
1-ch audio input and 1-ch audio output |
| Basic Event Detection |
Motion Detection ,Video Tampering Detection ,Alarm Input ,Alarm Output ,Exception |
| Client |
CMS ,Guarding Vision |
| Day & Night |
IR Cut Filter |
| Digital Zoom |
16× |
| Dimensions |
Φ 169 mm × 161 mm (Φ 6.65" × 6.34") |
| Focal Length |
4.8 mm to 120 mm ,25× optical |
| Focus Control |
Auto/Semi-automatic/Manual |
| FOV |
Horizontal field of view: 57.6° to 2.5° (wide-tele) Vertical field of view: 34.4° to 1.4° (wide-tele) Diagonal field of view: 64.5° to 2.9° (wide-tele) |
| Image Enhancement |
HLC/BLC/3D DNR/Defog/EIS/Regional Exposure/Regional Focus |
| Image Sensor |
1/2.8" progressive scan CMOS |
| IR Range |
Up to 50 m |
| Main Stream |
50Hz: 25fps (1920 × 1080 ,1280 × 960 ,1280 × 720) 50fps (1920 × 1080 ,1280 × 960 ,1280 × 720) 60Hz: 30fps (1920 × 1080 ,1280 × 960 ,1280 × 720) 60fps (1920 × 1080 ,1280 × 960 ,1280 × 720) |
| Material |
ADC12 ,PC ,PC+ABS ,SUS304 ,POM |
| Max. Resolution |
1920 × 1080 |
| Min. Illumination |
Color: 0.005 Lux @(F1.6 ,AGC ON) B/W: 0.001 Lux @(F1.6 ,AGC ON) 0 Lux with IR |
| Min. working distance |
10 mm to 1500 mm (wide-tele) |
| Network Interface |
1 RJ45 10 M/100 M Ethernet Interface; PoE+ (802.3 at ,class4) |
| Network Protocols |
IPv4/IPv6 ,HTTP ,HTTPS ,802.1x ,Qos ,FTP ,SMTP ,UPnP ,SNMP ,DNS ,DDNS ,NTP ,RTSP ,RTCP ,RTP ,TCP/IP ,UDP ,IGMP ,ICMP ,DHCP ,PPPoE ,Bonjour |
| Network Storage |
Built-in memory card slot ,support Micro SD/SDHC/SDXC ,up to 256 GB; NAS (NPS ,SMB/ CIPS) ,ANR |
| Operating Humidity |
≤ 90% |
| Operating Temperature |
-30°C to 65°C (-22°F to 149°F) |
| Power |
12 VDC & PoE+ (802.3 at ,class4) ,Max.:18 W (IR Max.5 W) |
| Privacy Masking |
24 programmable privacy masks |
| Protection |
IP66 Standard ,TVS 4000V Lightning Protection ,Surge Protection and Voltage Transient Protection |
| ROI encoding |
Main stream ,sub-stream ,and third stream respectively support four fixed areas. |
| Security Measures |
User authentication (ID and PW) ,Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering |
| Shutter Time |
1/1 s to 1/30 ,000 s |
| Simultaneous Live View |
Up to 20 channels |
| Smart detection |
Audio Exception Detection ,Face Detection ,Intrusion Detection ,Line Crossing Detection ,Region Entrance Detection ,Region Exiting Detection ,Unattended Baggage Detection ,Object Removal Detection |
| Smart IR |
Support |
| Smart Record |
ANR (Automatic Network Replenishment) ,Dual-VCA |
| Smart Tracking |
Manual Tracking ,Auto Tracking ,Event Tracking |
| Sub‐Stream |
50Hz: 25fps (704 × 576 ,640 × 480 ,352 × 288) 60Hz: 30fps (704 × 480 ,640 × 480 ,352 × 240) |
| Third Stream |
50Hz: 25fps (1920 × 1080 ,1280 × 960 ,1280 × 720 ,704 × 576 ,640 × 480 ,352 × 288) 60Hz: 30fps (1920 × 1080 ,1280 × 960 ,1280 × 720 ,704 × 480 ,640 × 480 ,352 × 240) |
| User/Host Level |
Up to 32 users. 3 levels: Administrator ,Operator and User |
| Web Browser |
IE 8 to 11 ,Chrome 31.0 to 44 ,Firefox 30.0 to 51 |
| Weight |
Approx. 2.45 kg (5.40 lb) |
| White Balance |
Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
| Zoom speed |
Approx. 3.2 s (optical lens ,wide-tele) |
| Camera Style |
Dome |
