2 MP HDCVI IR Dome CameraSeries

2MP HDCVI IR Dome CameraSeries

SKU: XVI-VD122R-IR-Z Categories: HD Cameras, WINIC

Angle of View	H: 105.9°~33.4°
Audio Interface	N/A
BLC Mode	BLC / HLC / DWDR
Casing	Aluminium
Certifications	CE (EN55032 , EN55024 , EN50130-4) FCC (CFR 47 FCC Part 15 subpartB , ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Day & Night	Auto (ICR) / Manual
Dimensions	Φ122mm×88.9mm (Φ4.8"×3.5")
Effective Pixels	1920(H)×1080(V) , 2MP
Electronic Shutter Speed	PAL: 1/25~1/100000s NTSC: 1/30~1/100000s
Lens Size	2.7-12mm
Focus Control	Motorized
Frame Rate	25/30fps@1080P , 25/30/50/60fps@720P
Gain Control	AGC
Gross Weight	0.59kg (1.30lb)
Image Sensor	1/2.7" CMOS
Protection	IK10 , IP67
IR Distance	Up to 30m (98feet)
IR LEDs	2
IR On/Off Control	Auto / Manual
Lens Type	Motorized Lens
Max Aperture	F1.8
Min. Illumination	0.02Lux/F1.8 , 30IRE , 0Lux IR on
Mount Type	Board-in
Net Weight	0.44kg (0.97lb)
Noise Reduction	2D
Operating Conditions	-30°C ~ +60°C (-22°F ~ +140°F) / Less than 95% RH * Start up should be done at above -30°C (-22°F)
OSD Menu	Multi-language
Pan / Tilt range	Pan: 0° ~ 355° Tilt: 0° ~ 75° Rotation: 0° ~ 355°
Power Consumption	Max 6.3W (12V DC , IR on)
Power Supply	12V DC ±30%
Resolution	1080P (1920×1080)
S/N Ratio	More than 65dB
Scanning System	Progressive
Smart IR	Auto / Manual
Storage Conditions	-30°C ~ +60°C (-22°F ~ +140°F) / Less than 95% RH
Video Output	1-channel BNC high definition video output / CVBS video output (Can switch)
WDR	DWDR
White Balance	Auto / Manual
Camera Style	Dome
