2MP Starlight HDCVI IR Bullet Camera

SKU: CVI-BU223R-IR-Z Categories: HD Cameras, WINIC

Angle of View	H: 102°~29°(40°~17°)
Audio Interface	N/A
BLC Mode	BLC / HLC / WDR
Casing	Aluminium
Certifications	CE (EN55032 , EN55024 , EN50130-4) FCC (CFR 47 FCC Part 15 subpartB , ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Close Focus Distance	200mm(1000mm) 7.87' (39.37')
Day & Night	Auto (ICR) / Manual
Dimensions	213.0mm×90.4mm×90.4mm (8.39"×3.56"×3.56")
Effective Pixels	1937(H)×1097(V) , 2.1MP
Electronic Shutter Speed	PAL: 1/4s~1/100000s NTSC: 1/3s~1/100000s
Lens Size	2.7-13.5mm
Focus Control	Auto / Manual
Frame Rate	25/30fps@1080P , 25/30fps@720P
Gain Control	AGC
Gross Weight	0.74kg (1.63lb)
Image Sensor	1/2.8" CMOS
Protection	IP67
IR Distance	Up to 60m (197feet)
IR LEDs	4
IR On/Off Control	Auto / Manual
Lens Type	Motorized Lens
Max Aperture	F1.3
Min. Illumination	0.005Lux/F1.3 , 30IRE , 0Lux IR on
Mount Type	Board-in
Net Weight	0.61kg (1.34lb)
Noise Reduction	2D / 3D
Operating Conditions	-40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH * Start up should be done at above -40°C (-40°F)
OSD Menu	Multi-language
Pan/Tilt Range (PTZ)	Pan: 0° ~ 360° Tilt: 0° ~ 87° Rotation: 0° ~ 360°
Power Consumption	Max 10.1W (12V DC , IR on)
Power Supply	12V DC ±25%
Resolution	1080P (1920×1080)
S/N Ratio	More than 65dB
Scanning System	Progressive
Smart IR	Auto / Manual
Storage Conditions	-40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH
Video Output	1-channel BNC high definition video output / CVBS video output (Can switch)
White Balance	Auto / Manual
Camera Resolutions	2 MP
Camera Style	Bullet
