3MP WDR Ultra-Smart Network Cameras
3MP WDR Ultra-Smart Network Cameras
- 1/2.8″ 3 Megapixel progressive scan Sony Exmor Sensor IMX123
- Support H.264/H.265 encoding
- Smart triple streams supported
- Max 30fps@3MP(2048×1536)
- Ultra WDR (Wide Dynamic Range) up to 140dB
- Ultra 3D DNR, Ultra Defog, ROI, EIS
- 2.8mm-12mm Motorized Lens(-Z)
- Smart detection: Face detection,Tripwire detection,Intrusion detection
- Scene change detection
- Auto back focus
- 100/1000M Base-T Ethernet
| Advanced Function |
People counting Heat map |
|---|---|
| Alarm |
1/1 channel In/Out |
| Angle of View |
H: 81.2°~25.8° |
| Backlight Compensation |
BLC / HLC / Ultra WDR (140dB) |
| Compatibility |
ONVIF ,PSIA ,CGI |
| Compression |
H.265/H.264 / MJPEG |
| Compression (audio) |
G.711a / G.711u/AAC |
| Day & Night |
Auto(ICR)/Color/B/W |
| Defog |
Ultra Defog |
| Dimensions |
Φ159mm×117.9mm |
| Effective Pixels |
2048(H)x1536(V) |
| EIS |
Support |
| Electronic Shutter Speed |
Auto/Manual 1/3(4)~1/100000s |
| Ethernet |
RJ-45 (10/100Base-T) |
| Focal Length |
2.8 -12mm motorized |
| Focus Control |
Auto |
| Frame Rate |
Main Stream 3M/1080P/720P(1~25/30fps) Sub Stream D1/CIF(1 ~ 25/30fps) Third Stream 1080P/720P/D1(1 ~ 25/30fps) |
| Gain Control |
Auto/Manual |
| Image Sensor |
1/2.8” 3Megapixel Exmor R CMOS |
| Protection |
IP66 |
| Interface |
1/1 channel In/Out |
| Lens Type |
Motorized Lens |
| Max Aperture |
F1.4 |
| Max. IR LEDs Length |
50m |
| Max. User Access |
20 users |
| Memory Slot |
Micro SD ,Max 128GB |
| Min. Illumination |
0. 01Lux/F1.4(Color) ,0Lux/F1.4(IR on) |
| Mount Type |
Board-in Type |
| Noise Reduction |
3D |
| PIR Sensor Range |
N/A |
| Power Consumption |
Max 12W |
| Power Supply |
DC12V/AC24V ,PoE(802.3af) |
| Privacy Masking |
Up to 4 areas |
| Protocol |
IPv4/IPv6 ,HTTP ,HTTPS ,SSL ,TCP/IP ,UDP ,UPnP ,ICMP ,IGMP ,SNMP ,RTSP ,RTP ,SMTP ,NTP ,DHCP ,DNS ,PPPOE ,DDNS ,FTP ,IP Filter ,QoS ,Bonjour |
| Resolution |
3M(2048×1536)/1080P(1920×1080)/720P(1280×720)/D1(704×576)/CIF(352×28 8) |
| ROI |
Up to 4 areas |
| RS485 |
N/A |
| S/N Ratio |
More than 50dB |
| Scanning System |
Progressive |
| Smart detection |
Tripwire Intrusion Scene change Missing/Abandoned Audio detect Face detect |
| Smart Phone |
iPhone ,iPad ,Android ,Windows Phone |
| Vandal Resistance |
IK10 |
| Video Bit Rate |
H.264: 40K ~ 10Mbps |
| Video Output |
1 port |
| Weight |
0.8kg |
| White Balance |
Auto |
| Wi-Fi |
N/A |
| Working Environment |
-30°C~+60°C ,Less than 90%RH |
