4K HDCVI IR Eyeball Camera

WINIC

4K HDCVI IR Eyeball Camera

Add to wishlist
Add to compare
SKU: XVI-EB182A-IRM 3.6 Categories: ,
  • 120dB True WDR, 3D NR
  • Max. 4K resolution
  • CVI/CVBS/AHD/TVI switchable
  • Built-in mic (-A)
  • Fixed lens (3.6mm)
  • Max. IR length 50m, smart IR
  • IP67, 12V±30%DC
Image Sensor

1/2.7 inch CMOS
Effective Pixels

3840 (H)×2160 (V)

,

4K
Electronic Shutter Speed

PAL: 1/3s-1/100000s NTSC: 1/4s-1/100000s
Color

White
Minimum Illumination

0.03Lux/F2.0

,

30IRE

,

0Lux IR on
IR Distance

Distance up to 50m (164.04ft)
Lens Size

3.6mm
Lens Type

Fixed Lens
Lens Mount

M12
Audio

Built-in Microphone
WDR

120dB
Power Supply

12V±30% DC
Power Consumption

Max 4.5W (12V DC

,

IR on)
Protection

IP67
Casing

Metal throughout the whole casing
Dimensions

Φ106mm×93.6mm (Φ4.17"×3.69")
Net Weight

470g (1.04lb)
Gross Weight

620g (1.37lb)
