- High quality image with 4 MP, 1/2.9″ CMOS sensor
- 2688 × 1520@30 fps in the main stream
- Ultra 265, H.265, H.264, MJPEG
- Dual streams
- 16X optical zoom
- LightHunter technology ensures ultra-high image quality in low illumination environment
- Smart IR, up to 100 m (328 ft) IR distance
- DC 12 V±10%, PoE+ (IEEE 802.3at)
- Alarm I/O: 2/1, audio I/O: 1/1
- IP66 ingress protection
- IK10 vandal resistant
| Lens Size |
5.5~ 88mm |
|---|---|
| Protection |
IK10 ,IP66 |
| Camera Resolutions |
4 MP |
| Sensor |
1/2.9" CMOS |
| Min. Illumination |
Color: 0.005 Lux (F1.78 ,AGC ON) ,0 Lux with IR |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| Shutter |
Auto/Manual ,1 ~ 1/100000s |
| WDR |
120 dB |
| S/N |
>56 dB |
| Iris |
F1.78-F3.73 |
| Illumination Distance (IR) |
Up to 100m (328 ft) IR range |
| Video Compression |
Ultra 265 ,H.265 ,H.264 ,MJPEG |
| Video Bit Rate |
128 Kbps to 16 Mbps |
| Digital Noise Reduction |
2D/3D DNR |
| Edge Storage |
MicroSD ,up to 512 GB |
| Network Storage |
ANR ,NAS (NFS) |
| Serial Port |
1*RS485 |
| Interface Network |
1 × RJ45 10 M/100 M Base-TX Ethernet |
| Power |
DC 12 V (±10% ,3A) ,PoE+ (IEEE 802.3at) |
| Power Consumption |
Max. 23 W |
| Power Interface |
Ø5.5 mm coaxial power plug |
| Dimensions |
Ø167 mm × 181 mm (Ø6.6" × 7.1") (Ø × H) |
| Weight |
2.3 kg (5.07 lb) |
| Reset Button |
Support |
| Surge Protection |
6 KV |
| Camera Style |
Dome |
