4MP 25x Starlight IR WizSense Network PTZ Camera
4MP 25x Starlight IR WizSense Network PTZ Camera
- 1/2.8″ 4Megapixel CMOS
- Powerful 25x optical zoom
- Starlight technology
- Max.25/30fps@4M
- Perimeter protection
- Support PoE+
- IR distance up to 100m
- SMD PLUS
- IP66
| Alarm input / output |
In/Out |
|---|---|
| Audio Input |
1 |
| Audio Output |
1 |
| Auto iris |
Auto/Manual |
| Bit Rate Control |
Variable/Constant |
| BLC |
Support |
| Certifications |
CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB ,ANSI C63.4-2014 UL: UL62368-1+CAN/CSA C22.2 ,No. 62368-1 |
| Close Focus Distance |
0.1 m–1.5 m (0.33 ft–4.92 ft) |
| Compression |
H.265+/H.265/H.264+/H.264/MJPEG (sub stream) |
| Compression (audio) |
G.711a; G.711Mu; AAC; G.722.1; G.726; MPEG2-Layer2; G.729 |
| Day & Night |
Auto(ICR)/Color/B/W |
| Defog |
Support |
| Digital Zoom |
16x |
| Dimensions |
Φ160 mm × 295 mm (6.30" × 11.61") |
| DORI Distance |
Detect 2540 m (8333.33 ft) Observe 1016 m (3333.33 ft) Recognize 508 m (1666.67 ft) Identify 254 m (833.33 ft) |
| Effective Pixels |
4MP |
| Electronic Image Stabilization (EIS) |
Support |
| Electronic Shutter Speed |
1/1 s–1/30 ,000 s |
| Ethernet |
RJ-45 (10/100Base-T) |
| Event Trigger |
Motion detection ,Video tampering ,Scene changing ,Network disconnection ,IP address conflict ,Illegal Access ,Storage anomaly |
| Face Detection |
Support |
| Flip |
180° |
| Focal Length |
4.8 mm–120 mm |
| Focus Control |
Auto/Semi-Auto/Manual |
| Frame Rate |
Main stream: 4MP/3MP/1080P/1.3MP/720P (1–25fps) Sub stream 1: D1/CIF (1–25fps) Sub stream 2: 1080P/1.3M/720P (1–25fps) |
| Gain Control |
Auto/Manual |
| Gross Weight |
4.8kg (10.58lb) |
| HLC |
Support |
| Horizontal Field of View |
H: 60.0°–2.5°; V: 30.8°–2.2°; D: 66.7°–2.9° |
| Idle Motion |
Preset/Tour/Pattern/Scanning |
| Illumination Distance |
100 m (328.08 ft) |
| Illuminator Number |
4 |
| Illuminator On/Off Control |
Zoom Prio/Manual/SmartIR |
| Image Sensor |
1/2.8" STARVIS™ CMOS |
| Protection |
IP66; TVS 6000V lightning proof; Surge protection |
| Interoperability |
ONVIF Profile S&G&T; CGI |
| IVS |
Object Abandoned/Missing |
| Management Software |
Smart PSS; DSS; DMSS |
| Manual Control Speed |
Pan: 0.1°–200°/s Tilt: 0.1°–120°/s |
| Max Aperture |
F1.6–F4.0 |
| Max. Resolution |
2560 (H) × 1440 (V) |
| Min. Illumination |
Color: 0.005Lux@F1.6 B/W: 0.0005Lux@F1.6 0Lux@F1.6 (IR light on) |
| Motion Detection |
Support |
| Net Weight |
3 kg (6.61 lb) |
| Network Storage |
NAS; Local PC; Micro SD card (256G) |
| Noise Reduction |
Ultra DNR (2D/3D) |
| Operating Humidity |
≤95% |
| Operating Temperature |
-40°C to +70°C (-40°F to +158°F) |
| Optical Zoom |
25x |
| Pan / Tilt range |
Pan: 0°–360° (endless) Tilt: -15°–90° (auto flip 180°) |
| Pattern |
5 |
| Perimeter Protection |
Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals ,rustling leaves ,bright lights ,etc. |
| Power Consumption |
13W 21W (IR on) |
| Power Supply |
DC 12V/3A PoE+ (802.3at) |
| Power-off Memory |
Support |
| Preset |
300 |
| Preset Speed |
Pan: 240°/s Tilt: 200°/s |
| Privacy Masking |
Up to 24 areas ,and up to 8 areas in the same view |
| Protocol |
IPv4; IPv6; HTTP; HTTPS; SSL; TCP/IP; UDP; UPnP; ICMP; IGMP; SNMPv1/v2c/v3(MIB-2); ARP; RTCP; RTSP; RTP; SMTP; NTP; DHCP; |
| protocol(PTZ) |
DH-SD Pelco-P/D (auto recognition) |
| RAM/ROM |
1GM/4GB |
| Region of Interest |
Support |
| Camera Resolutions |
4 MP |
| Scan |
5 |
| Scanning System |
Progressive |
| Smart Capture |
Support human ,motor vehicle and non-motor vehicle image capture. |
| Smart Phone |
IOS/Android |
| SMD PLUS |
Support |
| Speed Adjustment |
Support |
| Streaming Capability |
3 streams |
