4MP H.265+ Full HD TWDR Network EXIR Bullet Camera

4MP H.265+ Full HD TWDR Network EXIR Bullet Camera- 4mm Len, 50m IR

SKU: NC324-XB 4mm Categories: NETWORK CAMERAS, WINIC

1/3″ Progressive Scan CMOS
2560 × 1440@30fps
4 mm fixed lens
Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR
H.265+, H.265, H.264+, H.264
Three streams
120dB WDR
2 Behavior analyses, and face detection
BLC/3D DNR/ROI
IP67
Built-in micro SD/SDHC/SDXC card slot, up to 128 GB
3-Axis adjustment

3‐Axis Adjustment	Pan: 0° to 360° , tilt: 0° to 100° , rotate: 0° to 360°
Alarm Trigger	Motion detection , video tampering , network disconnected , IP address conflict , illegal login , HDD full , HDD error
API	ONVIF (PROFILE S , PROFILE G) , ISAPI
Auto iris	No
Behavior Analysis	Line crossing detection , intrusion detection
Client	iVMS‐4200 , Hik‐Connect , iVMS‐5200
Communication Interface	1 RJ45 10M/100M self‐adaptive Ethernet port
Day & Night	Auto/Schedule
Digital Noise Reduction	3D DNR
Dimensions	Camera: Φ 105 × 299.7 mm (Φ 4.1" × 11.8") Package: 386 × 156 × 155 mm (15.2" × 6.1" × 6.1")
Face Detection	Yes
Focal Length	4mm
Lens Size	4mm
FOV	2.8 mm: horizontal FOV: 98° , vertical FOV: 55° , diagonal FOV: 114° 4 mm: horizontal FOV: 78° , vertical FOV: 42° , diagonal FOV: 93° 6 mm: horizontal FOV: 48° , vertical FOV: 27° , diagonal FOV: 54° 8 mm: horizontal FOV: 37° , vertical FOV: 21° , diagonal FO
General Function	One‐key reset , anti‐flicker , three streams , heartbeat , mirror , password protection , privacy mask , watermark , IP address filter
H.264 Type	Main Profile/High Profile
H.264+	Main stream and sub‐stream support
H.265 Type	Main Profile
H.265+	Main stream and sub‐stream support
Image Enhancement	BLC/3D DNR
Image Sensor	1/3" Progressive Scan CMOS
Image Settings	Rotate mode , saturation , brightness , contrast , sharpness adjustable by client software or web browser
IR Range	Up to 50 m
Lens Mount	M12
Main Stream	50Hz:25fps (2560 × 1440 , 2304 × 1296 , 1920 × 1080) 60Hz: 30fps (2560 × 1440 , 2304 × 1296 , 1920 × 1080)
Material	Metal
Max Aperture	F1.6
Max. Resolution	2560 × 1440
Min. Illumination	Color: 0.01 Lux @ (F1.2 , AGC ON) , 0.018 Lux @ (F1.6 , AGC ON) , 0 Lux with IR
Network Protocols	TCP/IP , ICMP , HTTP , HTTPS , FTP , DHCP , DNS , DDNS , RTP , RTSP , RTCP , PPPoE , NTP , UPnP™ , SMTP , SNMP , IGMP , 802.1X , QoS , IPv6 , Bonjour
Network Storage	Support Micro SD/SDHC/SDXC card (128G) , local storage and NAS (NFS , SMB/CIFS) , ANR
On-Board Storage	Built‐in Micro SD/SDHC/SDXC slot , up to 128 GB
Operating Conditions	‐30 °C to +60 °C (‐22 °F to +140 °F) , Humidity 95% or less (non‐condensing)
Power Consumption	12 VDC , 0.6A , max. 7.5W PoE (802.3af , 37V to 57V) , 0.2A to 0.1A , max. 9.5W
Power Supply	12 VDC ± 25% , Φ 5.5 mm coaxial power plug PoE (802.3af , class 3)
Protection	IP67 TVS 2000V Lightning Protection , Surge Protection and Voltage Transient Protection
Region of Interest	1 fixed region for main stream and sub‐stream
Reset Button	Yes
Shutter Speed	1/3 s to 1/100 , 000 s
Simultaneous Live View	Up to 6 channels
Slow Shutter	Yes
Sub‐Stream	50Hz: 25fps (640 × 480 , 640 × 360 , 320 × 240) 60Hz: 30fps (640 × 480 , 640 × 360 , 320 × 240)
SVC	H.264 and H.265 encoding
Target Cropping	No
Third Stream	50Hz: 25fps (1280 × 720 , 640 × 360 , 352 × 288) 60Hz: 30fps (1280 × 720 , 640 × 360 , 352 × 240)
User/Host Level	Up to 32 users 3 levels: Administrator , Operator and User
Video Bit Rate	32 Kbps to 16 Mbps
Video Compression	Main stream: H.265/H.264 Sub‐stream: H.265/H.264/MJPEG Third stream: H.265/H.264
Video Output	No
Wavelength	850nm
Web Browser	IE8+ , Chrome 31.0‐44 , Firefox 30.0‐51 , Safari 8.0+
Weight	Camera: Approx. 1180 g (2.6 lb.) With Package: Approx. 1700 g (3.7 lb.)
Wide Dynamic Range	120dB
Camera Style	Bullet
