4MP Ture WDR Motorized focal IR VandalDome Network Camera

SKU: NC304-VDZ Categories: NETWORK CAMERAS, WINIC

1/3” Progressive Scan CMOS
Up to 4-megapixel resolution
120dB WDR
3D DNR
Motorized lens 2.8-12mm (-Z)
Up to 30 meters IR range
Built-in Micro SD/SDHC/SDXC card slot, up to 128 GB
Audio/alarm I/O (-S)
Mobile Monitoring via EZVIZ P2P or iVMS-4500
12V DC±10% & PoE(802.3af)
Support H.264+
IP66
IK10

Alarm Trigger	Intrusion Detection , Line Crossing detection , Motion detection , Dynamic Analysis , Tampering alarm , Network disconnect , IP address conflict , Storage exception
Angle Adjustment	Pan:0° – 355° , Tilt: 0° – 75° , Rotation: 0° – 355°
Audio Bit Rate	64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) *only for –S models
Audio Compression	G.711/G.726/MP2L2
Backlight Compensation	BLC
Communication Interface	1 RJ45 10M/100M Ethernet interface
Day & Night	Auto/Schedule/Triggered by Alarm In
Digital Noise Reduction	3D DNR
Dimensions	Φ140 x 99.9 mm (Φ 5.51” x 3.94”
Frame Rate	50Hz: 20fps (2688×1520) , 25fps(1920×1080) , 25fps(1280×720) 60Hz: 20fps (2688×1520) , 30fps (1920×1080) , 30fps(1280×720)
H.264 Type	Main Profile
Image Sensor	1/3” Progressive Scan CMOS
Image Settings	Rotate mode , Saturation , Brightness , Contrast adjustable by client software or web browser
Impact Protection	IEC60068-2-75Eh , 20J; EN50102 , up to IK10 -C: En50102 , up to IK8
Protection	IP66
IR Range	Approx 20 to 30 meters
Lens Size	2.8-12mm
Lens Mount	Φ14
Max. Resolution	2688×1520
Min. Illumination	0.01Lux @(F1.2 , AGC ON) , 0.014 Lux @(F1.4 , AGC ON) , 0 Lux with IR
Network Storage	NAS (Support NFS , SMB/CIFS) , ANR
On-Board Storage	Built-in Micro SD/SDHC/SDXC slot , up to 128GB
Operating Conditions	-10°C ~ 60°C (14°F ~ 140°F) Humidity 90% or less (non-condensing)
Power Consumption	Max. 5.5 W
Power Supply	12 VDC ± 10% , PoE (802.3af)
ROI	Support
Security	One-key reset , Flash-prevention , dual stream , heartbeat , mirror , password protection , privacy mask , watermark , IP address filtering , Anonymous access
Shutter Speed	1/3 s ~ 1/10 , 000 s
Standard	ONVIF (PROFILE S , PROFILE G) , PSIA , CGI , ISAPI
Video Bit Rate	32 Kbps ~ 16 Mbps
Video Compression	H.264 / MJPEG/H.264+
Weight	1000g (2.20lbs)
Wide Dynamic Range	120dB
Lens Type	Motorized Lens
Camera Style	Dome
