AcuSense 4 MP IR Fixed Turret Network Camera

SKU: NC354-XDAU/SL 2.8mm Categories: NETWORK CAMERAS, WINIC

High quality imaging with 4 MP resolution
Excellent low-light performance
Clear imaging against strong back light due to 120 dB true WDR technology
Efficient H.265+ compression technology
False alarm reduction through human and vehicle target classification based on deep learning
Active strobe light and audio alarm to warn intruders off
Provides real-time security via built-in two-way audio
Water and dust resistant (IP66)

Camera Style	Turret
Lens Type	Fixed Lens
Image Sensor	1/2.7" Progressive Scan CMOS
Min.Illumination	Color: 0.003 Lux @ (F1.4 , AGC ON)
Shutter Speed	1/3 s to 1/100 , 000 s
Audio	Built-in Microphone , Built-in Speaker
Aperture	F1.4
Lens Size	2.8mm
Lens Mount	M12
Day & Night	ICR Cut
P/N	P/N
Wide Dynamic Range	120dB
Angle Adjustment	Pan: 0° to 360° , tilt: 0° to 75° , rotate: 0° to 360°
IR Range	Up to 30 m
Wavelength	850nm
Communication Interface	1 RJ45 10M/100M self-adaptive Ethernet port
Power Supply	12 VDC , 0.65 A , max. 7.8 W PoE: (802.3af , 36 V to 57 V) , 0.25A to 0.15 A , max. 8.8 W
Power Consumption	Ø5.5 mm coaxial power plug
Protection	IP66
Material	Metal except for trim ring
Package Dimension	170 × 170 × 150 mm (6.9" × 6.9" × 5.9")
Camera Dimension	Ø138.3 × 124.5 mm (Ø5.4″ × 4.9″)
Camera Weight	Approx. 800 g (1.8 lb.)
With Package Weight	Approx. 1093 g (2.4 lb.)

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Firmware	Description	File	Download
NC344-X/NC35X		NC35X_IPC_G3_EN_NEU_5.5.800_210729	Download
