Supports call and intercom with the connected indoor stations and UNV Link.
Standard recess mount bracket for recess mount.
Built-in heating module supports operation at a very low temperature.
Supports controlling two doors.
Supports braille keypads.
Front metal casing.
Supports configuration in batches.
Supports security protection alarm and tamper alarm triggered by door magnet, infrared, etc.
Built-in IC card reader.
Supports connecting a door control security module via a private RS485 interface to prevent the door from being opened in the event of malicious damage to the device.
Adopts Uniview’s proprietary deep learning algorithm model, with the smart recognition rate exceeding 99%, false recognition rate below 1%, and maximum recognition speed of 0.2 seconds.
2MP low illumination, high definition, star light image sensor.
Supports auto illumination.

Operation System

Linux

Illuminator

IR illuminator

Power Consumption

9W

Volume Adjustment

Support

Audio Quality

Noise reduction

,

echo cancellation

,

auto gain control

Audio

Built-in Microphone

,

Built-in Speaker

Card Capacity

15000

Audio Compression Bitrate

128Kbps

Protection

IP65

,

IK08

Power Supply

DC12V ±25% (VDD12V/GND)、IEEE802.3af PoE power supply

Weight

912g

Screen Size

3.97 inch

Interface

Power supply*1

,

network interface*1

,

RS485*1

,

Wiegand interface*1 (supports input or output mode)

,

door lock interface*2

,

IO input*4

,

IO output*2

,

door opening button*2

,

door magnet*2

,

tamper button*1

Dimensions (L x W x H)

125.0mm x 52.5mmx 358.0mm

WDR

Support

Protocol

Private protocol

Button

15 buttons (with LED backlight)

,

with braille in rows 1-4 Keypad layout: Row 1: 1/2/3 Row 2: 4/5/6 Row 3: 7/8/9 Row 4: */0/# Row 5: Management center/cancel/call
