AR346-16/A 16 Channel H.265 8 MP 1U 2HDD BAY TVI xDVR
Click to enlarge
WINIC

AR336-8/A 8 Channel 8 MP 1U 2HDD TVI 4.0 XDVR

TURBO ACUSENSE TVI DVR

  • Deep learning-based motion detection 2.0 for all analog channels
  • Deep learning-based perimeter protection
  • H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 video compression
  • HDTVI/AHD/CVI/CVBS/IP video inputs
  • Audio via coaxial cable
  • Up to 16/32-ch IP camera inputs (up to 8 MP)
  • Up to 10 TB capacity per HDD
Add to wishlist
SKU: AR336-8/A Categories: ,
Description

Product Overview

The AR336-8/A is a high-performance hybrid DVR supporting HDTVI, HDCVI, AHD, CVBS, and IP cameras. It features deep learning-based motion detection 2.0 and perimeter protection for precise human and vehicle recognition, reducing false alarms. With H.265 Pro+ video compression, it maximizes storage efficiency while maintaining high-definition 8 MP video quality. The system supports simultaneous HDMI/VGA output, audio via coaxial cable, smart VCA functions, and cloud storage compatibility. Dual SATA interfaces enable up to 2 hot-swappable HDDs for reliable storage.Key Features

Compression and Recording

  • H.265 Pro+ video compression improves encoding efficiency, and reduces data storage costs
  • Recording at up to 8 MP resolution

Storage and Playback

  • 2 SATA interfaces
  • Smart search for efficient playback
  • Support the third party cloud storage

Smart Function

  • Deep learning-based motion detection, and perimeter protection (line crossing and intrusion detection)
  • Support multiple VCA (Video Content Analytics) events for both analog and smart IP cameras

Network & Ethernet Access

  • Compatible with major Wi-Fi dongle products in the market
  • Hik-Connect & DDNS (Dynamic Domain Name System) for easy network management
  • Output bandwidth limit configurable
Additional information
Human/Vehicle Analysis

4-ch
Video compression

H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding resolution

Main stream: 8 MP@8fps /5 MP@12fps /3K@12 fps /4 MP@15fps /3 MP@18fps 1080p /720p /WD1 /4CIF /VGA /CIF@25 fps (P)/30 fps (N) Sub-stream: WD1 /4CIF /CIF@25 fps (P)/30 fps (N)
IP Video Input

4-ch
Video Bit Rate

32 Kbps to 10 Mbps
Audio bit rate

64 Kbps
Synchronous playback

8-ch
HDD Support

Capacity

Up to 10 TB capacity for each disk
Serial interface

RS-485(half-duplex)
Power

DC 12V
Consumption (without HDD)

≤15 W
Dimensions

380×320×48 mm(15.0×12.6×1.9 inch)
Weight

≤1.78 kg(3.9 lb)
Download

Datasheet

Related Firmware

Firmware Name Description Associated File Actions
AR336-4/A & AR336-8/A & AR336-16/A DZ_K20A8S_EUROPE_ML_NEU_V4.75.000_build240507_OEM3 Download
