H.265+/H.265/H.264+/H.264 video formats
Up to 32-ch IP camera inputs
Up to 32-ch@1080p decoding capacity
Up to 320 Mbps incoming bandwidth
Up to 8-ch IP speakers can be connected
*Professional and Reliability
* H.265+ compression effectively reduces the storage space by up to 75%
* Dual-stream recording saves bandwidth
* Adopt stream over TLS encryption technology which provides more secure stream transmission service
* Support double verification for playback and downloading
*HD Video Output
* Provide independent HDMI and VGA outputs
* HDMI video output at up to 8K resolution
* Dual 4K HDMI output resolution
*Storage and Playback
* Up to 4 SATA interfaces for HDD connection
* 16-ch synchronous playback
*Smart ＆ POS Function
* Support multiple VCA (Video Content Analytics) events
* Configurable special camera smart functions, such as VCA detection (motion, line crossing, intrusion, etc.), heat map, ANPR, and
people counting
* POS information overlay on live view and playback, and POS triggered recording and alarm
*Network ＆ Ethernet Access
* 16 independent PoE network interfaces
* 1 self-adaptive 10/100/1000 Mbps Ethernet interface
* Hik-Connect ＆ DDNS (Dynamic Domain Name System) for easy network management
* Smooth streaming technology
* Support web access without plug-in
32-ch 1.5U 16 PoE 8K Accsense NVR
Embedded 8K Plug&Play NVR
| Channel |
32 Channel |
|---|---|
| IP Video Input |
32-ch Up to 32 MP resolution *: After ultra HD resolution mode is enabled ,the NVR supports up to 8-ch 32 MP/24 MP IP video inputs. |
| Incoming Bandwidth |
320Mbps |
| Outgoing Bandwidth |
400Mbps |
| VGA Output |
1920 × 1080/60Hz ,1600 × 1200/60Hz ,1280 × 1024/60Hz ,1280 × 720/60Hz ,1024 × 768/60Hz |
| Video Output Mode |
HDMI1/VGA simultaneous output ,HDMI2/VGA independent output |
| CVBS Output |
1-ch ,BNC (1.0 Vp-p ,75 Ω) ,resolution: PAL: 704 × 576 ,NTSC: 704 × 480 |
| Audio Output |
1-ch ,RCA (Linear ,1 KΩ) |
| Two-Way Audio |
1-ch ,RCA (2.0 Vp-p ,1 KΩ ,using the audio input) |
| Decoding Format |
H.265+/H.265/H.264+/H.264 |
| Synchronous Playback |
16-ch |
| Decoding Capability |
2-ch@32 MP (30 fps) + 2-ch@8 MP (30 fps)/10-ch@8 MP (30 fps)/20-ch@4 MP (30 fps)/40-ch@1080p (30 fps) |
| Remote Connection |
128 |
| Interface |
16 ,RJ-45 10/100 Mbps self-adaptive Ethernet interface |
| Power |
≤ 200 W |
| Standard |
IEEE 802.3 af/at |
| eSATA |
1 eSATA interface |
| SATA |
4 SATA interfaces |
| Capacity |
Up to 16 TB capacity for each disk |
| Serial Interface |
2 RS-485 (half-duplex) ,1 RS-232 |
| USB Interface |
Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 |
| Power Supply |
100 to 240 VAC ,50 to 60 Hz |
| Consumption |
≤15W(without HDD and PoE off) |
| Dimension(W×D×H) |
445 × 400 × 75 mm ( 17.5"× 15.7" × 3.0") |
| Weight |
≤ 5 kg (without HDD ,11 lb.) |
Only logged in customers who have purchased this product may leave a review.
Datasheet
Related Firmware
| Firmware | Description | File | Download |
|---|---|---|---|
| NR52P6-16/32 | DZ_K21B1_ML_NEU_V4.63.010_241225_OEM3 | Download |
