HD CCTV Via Twisted Pair

Features:

• Compatible with all HD-CVI, HD-TVI, HD-AHD
• Up to 450m for 720P CVI Cameras
• Up to 250m for 1080P CVI Cameras
• Up to 250m for 720P & 1080P TVI Cameras
• Up to 320m for 720P AHD cameras
• NTSC, PAL and SECAM video formats
• no power required
• 60dB cross talk and noise immunity
• Compact size and easy installation
• Built-in transient suppression protection
• Innovative combinable design

Technical Specifications:

• Frequency response: DC to 60Mhz
• Attenuation: 0.5dB type
• CMRR: 60dB
• Surge protection: 4KV, ESD:8KV
• Connectors: Male BNC and terminal blocks
• Impendance:BNC 75ohms, Terminal: 100ohms
• Working Temperature: -10°C to +70°C
• Storage Temperature: -30°C to +70°C
• Humidity:0 to 95%
• Dimension 33m*17mm*16mm(excluding connectors)
• Material ABS Plastic
