Mifare Card Reader With keypad
Mifare Card Reader With keypad
- Equipped with the 32-bit high-speed processor
- RS-485 and Wiegand (W26/W34) protocol
- Build-in EM card reading module (Frequency:125KHz).
- Supports reading ID card
- Build-in Mifare card reading module (Frequency: 13.56MHz).
- Meets the standard of ISO 14443-A. Supports reading Mifare cardS
- Supports tampering alarm
- Built-in buzzer for identifying the reading status
- Online upgrade function
- Watchdog design for repairing itself in case that exception occurs, to ensure the long service life of the reader
| Power Supply |
12V DC |
|---|---|
| Power Consumption |
≤2W |
| Processor |
32-bit |
| Reading Range |
≤50mm (≤1.97") |
| ID Settings |
via DIP Switch |
| Communication Interface |
RS-485/Wiegand (Set via DIP Switch) |
| Audio Alert |
Beeper |
| Keypad |
Keypad with 12 Keys (0~9 ,* ,#) |
| LED Indicator |
Power Indicator ,Status Indicator |
| Dimensions |
115mm × 44mm × 22mm (4.53” × 1.73” × 0.87”) |
| Protection |
IP 65 |
| Installing Method |
Wall Mounting with Screws; Do Not Support Gang Box |
