NR33P6-16/D 16 Channel 4K 160M 1U 16 POE AcuSense NVR

16 Channel 4K 160M 1U 16 POE AcuSense NVR

Up to 16-ch IP camera inputs, plug & play with 16 power-over-Ethernet (PoE) interfaces
H.265+/H.265/H.264+/H.264 video formats
Up to 2-ch@12 MP or 3-ch@8 MP or 6-ch@4 MP or 12-ch@1080p decoding capacity
Up to 160 Mbps incoming bandwidth
Adopt AcuSense technology to minimize manual effort and security costs
Smart Function: All channels support Motion Detection 2.0
2-ch video analysis for human and vehicle recognition to reduce false alarm
1-ch facial recognition for video stream, or 4-ch facial recognition for face picture
Smart search for the selected area in the video, and smart playback to improve the playback efficiency

Description

Product Overview

The NR33P6-16/D AcuSense NVR provides high-resolution 4K surveillance for up to 16 IP cameras. Each channel supports flexible decoding up to 12 MP, ensuring detailed monitoring. With integrated 16 PoE ports, installation is simplified and network wiring is minimized. AcuSense technology enables human and vehicle detection to reduce false alarms and lower security management costs. The recorder supports facial recognition on selected video streams or face images for precise identification. Smart search and intelligent playback enhance efficiency when reviewing events. Compatible with H.265+/H.265/H.264+/H.264 formats, it delivers a balance of storage efficiency and image clarity, suitable for offices, retail environments, and small enterprises.

Key Features

16 PoE Channels: Plug-and-play connectivity for all cameras with power supplied via Ethernet.
High-Resolution Decoding: Supports 12 MP, 8 MP, 4 MP, and 1080p streams for versatile setups.
AcuSense AI Analytics: Human and vehicle detection reduces false alarms.
Facial Recognition: 1-channel video stream or 4-channel face image recognition.
Smart Search & Playback: Quickly locate events in recorded footage.
Motion Detection 2.0: All channels provide advanced motion-triggered alerts.
Flexible Bandwidth Management: Up to 160 Mbps incoming bandwidth for smooth recording.

Key Specifications

Camera Input: Up to 16 IP channels with 16 PoE ports.
Video Compression: H.265+/H.265/H.264+/H.264.
Decoding Capacity: 2-ch @12 MP, 3-ch @8 MP, 6-ch @4 MP, 12-ch @1080p.
Incoming Bandwidth: Up to 160 Mbps.
Smart Functions: Motion detection, human & vehicle recognition, facial recognition.

Additional information

Channel	16 Channel
Facial Detection and Analytics	Face picture comparison , human face capture , face picture search
Face Picture Library	Up to 16 face picture libraries , with up to 20 , 000 face pictures in total(each picture≤4 MB , total capacity≤1GB)
Face Picture Comparison	4-ch face picture comparison alarm
IP Video Input	16-ch
Incoming Bandwidth	160Mbps
Outgoing Bandwidth	160Mbps
HDMI Output	1-ch , 4K(3840×2160)/30Hz , 2K(2560×1440)/60Hz , 1920×1080/60Hz , 1600×1200/60Hz , 1280×1024/60Hz , 1280×720/60Hz , 1024×768/60Hz
VGA Output	1-ch , 1920×1080/60Hz , 1280×1024/60Hz , 1280×720/60Hz
Video Output Mode	HDMI/VGA independent output
Audio Output	1-ch , RCA(2.0Vp-p , 1KΩ , using the audio input)
Two-Way Audio	1-ch , RCA(Linear , 1KΩ)
Decoding Format	H.265/H.265+/H.264+/H.264
Synchronous playback	16-ch
Interface	16 , RJ-4510/100Mbps self-adaptive Ethernet interface
Power	≤200W
HDD Support	2 HDD
Capacity	Up to 10TB capacity for each HDD
USB Interface	Front panel:1×USB2.0;Rear panel:1×USB2.0
Power Supply	100 to 240VAC , 50 to 60Hz
Consumption	≤15W(without HDD , and PoE off)
Dimension(W×D×H)	385mm×315mm×52mm(15.2"×12.4"×2.0")
Weight	≤3kg(without HDD , 6.6lb.)
