OEU-202S-HMK4 4-Button Metal Villa Video Door Station with IC Card Access
Click to enlarge
UNV

OEU-202S-HMK4 4-Button Metal Villa Video Door Station with IC Card Access

4-Button Metal Villa Video Door Station with IC Card Access

Add to wishlist
SKU: OEU-202S-HMK4 Category:
Description
  • Optional recess box for recess mount.
  • Supports power output, which can be enabled or disabled on the Web interface.
  • Built-in heating module supports operation at a very low temperature.
  • Metal casing.
  • Supports batch configuration.
  • Supports call and intercom with the connected indoor stations and UNV Link.
  • Supports video monitoring, security alarm, and tamper alarm.
  • Built-in IC card reader.
  • Built-in mic & speaker
Additional information
Operation System

Linux
Supplement Light

IR light (adaptive)
Power Consumption

PoE: 6.48W DC12V: 5.35W
Volume Adjustment

Support
Audio Quality

Noise suppression

,

echo cancellation

,

AGC
Audio

Built-in Microphone

,

Built-in Speaker
Card Capacity

10000
Audio Compression Bitrate

128Kbps
Protection

IP65

,

IK08
Power Supply

DC12V ±25%

,

IEEE802.3af PoE power suppl
Weight

680g
Network

100Mbps network port

,

supports IEEE802.3af PoE power supply
Interface

Power*1

,

network port*1

,

RS485*1

,

Wiegand*1

,

IO input*4

,

door lock*2 (support electric lock/door magnet)

,

tamper button*1
Dimensions (L x W x H)

96mm*176mm*33mm
WDR

DWDR
Protocol

Private protocol
Button

4 x Call button
