Supports mechanical chime and wireless chime.
Supports connection to a Uniview NVR for live view, playback, and alarm search.
Supports reporting motion detection alarms, human body detection alarms, and package detection alarms to UNV-Link and NVR.
3 MP + 2 MP dual cameras: The main camera for observing visitors, and the sub camera for monitoring the ground in front of the door, providing a wider view.
Supports noise suppression.
Supports true HDR and WDR, capturing clearer images in backlit scenes.
Supports calling the UNV-Link app, allows you to answer visitor calls anytime, anywhere using the app.
Supports Sub-1GHz wireless chime.
Supports dual-band Wi-Fi (2.4 GHz and 5 GHz) and Wi-Fi 6, faster video streaming and real-time monitoring.
Supports network connection through Bluetooth, quick and simple.
Built-in 8 GB eMMC storage, no extra storage costs necessary.

Resolution -- main camera

3MP

Resolution -- sub camera

2MP

power kit

240 mAH rechargeable lithium battery (for mechanical chime)

Motion detection alarm

Support

Operating frequency band

2.4 GHz and 5G Hz

BLE function

Compatible

,

integrated BLE

,

supports network connection via Bluetooth

SUB-1G

Supported

,

for chime connection

Chimes

Max. 3 wireless chimes or 1 mechanical chime

Reset button

1 micro switch for both pairing and reset

Audio

Built-in Microphone

Network protocol

TCP/IP

,

IPv4

,

HTTP

,

RTP

,

RTSP

,

NTP

Illumination distance

IR: 5 meters White light: 2 meters

Min. Illumination

0.02 lux

Dimensions

55.8 mm × 156.5 mm × 27.9 mm

Power consumption

10W

Weight

Net weight: 142g Gross weight: 295g

Ingress protection

IP65

WDR

Supports DWDR

,

main camera 80dB

,

sub camera 58dB

Video compression

H.265

,

H.264

Audio bit rate

128 Kbps
