NVR301-04S3-P4
Support Ultra 265/H.265/H.264 video formats
4-channel input
Plug & Play with 4 independent PoE network interfaces
Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile T
Support 1-ch HDMI, 1-ch VGA
HDMI and VGA simultaneous output
Up to 8MP resolution recording
1 SATA HDD
Support cloud upgrade
IPC3614LB-AF28K-DL
High quality image with 4MP, 1/3″CMOS sensor
4MP (2560*1440)@ 25/20fps; 3MP (2304*1296) @30/25fps; 2MP (1920*1080) @30/25fps
Ultra H.265,H.265, H.264
Support 9:16 Corridor Mode
Built-in Mic
Smart IR, up to 30m (98ft) IR distance
Warm Light, up to 30m (98ft) warm light distance
2D/3D DNR (Digital Noise Reduction)
| Model |
NVR301-04S3-P4 |
|---|---|
| IP Video Input |
4-ch |
| Incoming Bandwidth |
64Mbps |
| Outgoing Bandwidth |
48Mbps |
| Remote Users |
128 |
| Decoding format |
Ultra 265/H.265/H.264 |
| Capability |
1 x 4K@30 ,4 x 5MP@25 ,4 x 4MP@25 ,4 x 3MP@25 ,4 x 1080p@30 |
| Capacity |
Up to 8TB for each disk |
| Network Interface |
1 RJ-45 10M/100Mself-adaptive Ethernet Interface |
| USB Interface |
Rear panel: 2 x USB2.0 |
| Interface |
4 RJ-45 10M/100Mself-adaptive Ethernet Interface |
| Max Power |
Max 30W for single port Max 54W in total |
| Supported Standard |
IEEE 802.3at ,IEEE 802.3af |
| Power Supply |
48V DC Power Consumption: ≤9 W (without HDD) |
| Dimensions (W×D×H) |
260mm ×240mm × 46 mm (10.2" × 9.4" ×1.8") |
| Weight (without HDD) |
≤1.1kg (2.43lb) |
