Multiple working modes to address your business needs: Default(Normal mode), VLAN(Secure mode), EXTEND(Surveillance mode)
Support port traffic control
Support for secure mode, all downlink ports can communicate only with uplink ports
Up to 250m transmission distance on surveillance mode
Support buffer optimization
All metal housing, safe and reliable
| Ports Type |
16×100Mbps PoE ports (RJ45)+ 1×1000Mbps Gigaethernet ports +1×1000Mbps Combo ports |
|---|---|
| Switching capacity |
7.2 Gbps |
| Packet Buffer |
4 M bit |
| MAC |
16K |
| Forwarding performance |
5.36Mpps |
| Prior Ports |
1 to 8 |
| Standards |
IEEE802.3 ,IEEE802.3u ,IEEE802.3z ,IEEE802.3ab ,IEEE802.3x ,IEEE802.3af ,IEEE802.3at ,IEEE802.3az |
| Power Supply |
AC: 100 to 240V ,50/60Hz |
| PoE Standard |
IEEE 802.3 at ,IEEE 802.3af |
| PoE Mode |
ModeB (4578) |
| Max.PoE Power |
Max capacity:250W Max capacity for single port: 30W |
| Max.Power |
265W |
| Cooling Fans |
1 |
| Dimensions (W×D×H) |
440*195*44mm |
| Operating Temperature |
0°C to 40°C (32°F to 104°F) |
| Operating Humidity |
10% to 90% (noncondensing) |
| Weight |
2.12KG |
