UNV

Optics

• Built-in lens supports motorized zoom to adapt to different scenes and allows for easy installation.
• Automatic gain control, white balance, and WDR for various light conditions.

Compression

• Supports triple streams.
• Advanced H.265 encoding technology improves compression efficiency.
• Custom OSD allows various vehicle information to be overlaid on the video image.

Functions

• Built-in vehicle and license plate recognition algorithm can recognize standard license plates of multiple countries.
• Supports capturing vehicle head only.
• Supports plate allowlist and blocklist configuration.
• Supports vehicle access control when connected to a barrier.
• Supports Micro SD cards of up to 256GB.
• Automatic network replenishment (ANR) allows to automatically store video to SD card in case of network disconnection.
•  Supports audio collection and intercom.

Network

• Network auto-adaptability ensures smooth live video in relatively bad network conditions such as packet loss.
•  Supports SNMP.
• Supports UNP for NAT traversal between public and private networks.
• Supports integration with the third party via SDK or HTTP.

Network Security

• Supports authorized user access by password. Weak password detection and account lock-up when failed login attempts reach the upper limit enhance password security.
• Supports Web access via HTTPS.
•  RTSP authentication prevents unauthorized video stream requests.
• IP address filtering prevents illegal access from untrusted IP addresses.
• Gateway ARP protection prevents MAC address spoofing.

Structure

• Supports DC 12V and PoE (802.3at) power supplies.
• Cast aluminum body offers excellent heat dissipation.
• 3-axis mounting bracket for various installation scenarios.
• A junction box on the mounting bracket is convenient for storing tail cables.
•  IP67 and IK10 protection.
