Product Overview

The POE-SW16PG-2GF-250 is a high-performance Gigabit PoE switch designed to power and connect multiple network devices in surveillance and enterprise networking environments. Equipped with 16 PoE ports and additional Gigabit uplink connectivity, it enables centralized power delivery and data transmission for devices such as IP cameras, wireless access points, and network terminals. The integrated digital display provides real-time visibility of the PoE power status, allowing users to monitor system operation easily. Designed for stable network performance, the switch supports high-speed Gigabit communication while ensuring efficient heat dissipation. Its robust architecture simplifies network deployment by reducing the need for separate power infrastructure.

Key Features

• 16-Port PoE Power Delivery: Provides centralized power and data connectivity for multiple PoE devices such as IP cameras and wireless access points.c
• Gigabit Network Performance: High-speed Ethernet ports ensure smooth data transmission for bandwidth-intensive surveillance applications.
• Digital Power Display: Built-in digital display enables real-time monitoring of PoE power consumption and system status.
• Integrated Power and Data Transmission: Delivers both network connectivity and power through a single Ethernet cable.
• Reliable System Operation: Designed with optimized ventilation and thermal structure for stable long-term performance.
• Simplified Deployment: Centralized PoE switching reduces wiring complexity and installation costs in large networks.

Key Specifications

• PoE Ports: 16 × Gigabit PoE ports
• Uplink Ports: 2 × Gigabit uplink ports
• Network Speed: 10/100/1000 Mbps Ethernet
• PoE Function: Power and data transmission via Ethernet cable
• Monitoring: Integrated digital display for PoE power status

Product Overview

The POE-SW24P-2G-440 is a high-performance 24-port unmanaged PoE switch designed for stable network deployment. Supporting IEEE 802.3af/at PoE standards, each port can provide up to 30W, with a total PoE budget of 370W. Its 10/100Mbps Auto-MDIX ports enable flexible connectivity, while the first eight ports are designated as high-priority for essential devices. With an 8.8 Gbps switching fabric and 2.75 Mbits RAM buffer, the switch ensures smooth, non-blocking data transmission. The device is equipped with 4 KV surge protection, supports IEEE 802.3x flow control, and allows extended transmission up to 250 meters in Extend mode. Designed in a durable metal enclosure, it also offers optional SFP modules for long-distance fiber connections, combining reliability, performance, and ease of installation.

Key Features

• High PoE Output: Each port delivers up to 30W, supporting a total 370W PoE budget
• Plug-and-Play Design: No complex configuration required, instant deployment
• Priority Ports: Ports 1-8 can handle critical devices with high reliability
• Extended Transmission: Up to 250m distance over CAT 5e cables in Extend mode
• Robust Protection: 4 KV surge protection ensures safe operation for connected devices
• Smooth Performance: 8.8 Gbps switching capacity and 2.75 Mbits RAM buffer for efficient data forwarding
• Optional Fiber Uplink: Supports 100M/1000M SFP modules for long-distance connections

Key Specifications

• Network Ports: 24 x 10/100Mbps PoE RJ45 + 2 x 1000M Combo uplink
• PoE Standard: IEEE 802.3af/at, max 30W per port, 370W total
• Switching Capacity: 8.8 Gbps with 6.55Mpps packet forwarding rate
• MAC Table Size: 4K entries, store-and-forward mode

Product Overview

POE-SW8P-2G-96 is a 10-port 100M digital PoE switch independently developed by acorid Communication, providing 10* 10/100M adaptive RJ45 ports. Each RJ45 port supports MDI/MDIX auto flip and wire-speed forwarding functions. The downstream ports all support the IEEE802.3af/at standard PoE power supply function, can automatically detect and identify the power receiving equipment that meets the standard, and supply power to it through the network cable. The device supports digital display of power to prevent overload of usage. The device is plug and play, no configuration is required, and it is simple and convenient to use. It can be used in the access layer of security monitoring, hotels, campuses, factory dormitories and wireless coverage of small and medium-sized enterprises.

Key Features

• Large buffer design, high-definition video does not freeze
• Support IEEE 802.3x full-duplex flow control and Backpressure half-duplex flow
• Each RJ45 port supports MDI/MDIX auto flip and wire-speed forwarding functions

Operating Mode

• Provides three exchange modes.
• Standard mode: All ports can communicate freely after opening. Suitable for ordinary data transmission environment
• VLAN mode: After opening, all downstream ports cannot communicate with each other, which can isolate broadcast storms and prevent ARP viruses
• Extend mode: After opening, the rate of all downlink ports becomes 10M, and the transmission distance can
  reach 250m.

PoE Power Supply Capability

• Support IEEE 802.3af/at PoE power supply standard
• The maximum output power of a single port can reach 30W
• Smart Link power management, StepLink step-by-step start function to escort the safe and stable operation of Kedi PoE switches
• Automatic detection and identification of standard PoE power receiving equipment, intelligent power supply, will not burn non-standard PoE power receiving equipment or ordinary equipment
• The PoE port supports a priority mechanism, when the remaining power is insufficient, the power supply of the high-priority port is guaranteed first

Product Reliability

• The host has a low power consumption design and natural heat dissipation to ensure stable operation of the product.
• High redundancy design, providing long-term stable PoE power output.
• 0~45℃ working temperature improves product stability in a wide temperature environment

Easy To Use

• Plug and play, no need to configure, simple and convenient
• Users can easily understand the working status of the equipment through the power indicator (Power), port status indicator (Link/Act), and digital tube power display

Product Overview

W-Poe/1ch high power over enthernet midspans and splitters offer an easy fast and cost effective solution for powering network video products. power and data are combined on a single cable, thus eliminating the need for extra power lines and also reducing instalation costs and manpower.

Key Features

• High-Power PoE Delivery: Provides up to 30W for network devices
• Standards Compliant: Fully supports IEEE 802.3af/at
• Gigabit Data Support: 10/100/1000 Mbps RJ45 transmission
• Plug-and-Play: Easy setup, no configuration required
• Cost-Efficient Installation: Combines power and data on a single cable
• Compact & Lightweight: Small footprint (61 x 40 x 12 mm, 200g)
• Power Cable Included: Ready for immediate deployment

Key Specifications

• Ports: 1 x RJ45 input, 1 x 10/100Base-TX output
• Output Power: 30W max
• Data Rate: 10/100/1000 Mbps
• Input Power: 90–240V AC, 50/60Hz
