MD-IO84B I/O Expansion Module for AC-225x-B and AC-425x-B Access Control Panels
SKU:
MD-IO84B
- Eight additional supervised inputs
- Four additional fully programmable relay outputs
- LED status feedback for 12 V power and relay activation
- Cost effective and simple installation
- Compatible with Rosslare’s AC-225x-B, AC-425x-B networked access control panels
- Input and output configurability using Rosslare’s AxTraxNG or AxTraxPro Access Control Management Software
MD-N32 RS-232 to TCP/IP Gateway for Access Control Panels
SKU:
MD-N32
MAIN FEATURES
- Universal RS-232 to TCP/IP gateway for general use
- Supports DHCP dynamic IP addressing
- +12 VDC jack power input connector
- RS-232 speed from 1200 bps to 230.4 Kbps
- Bi-directional conversion of RS-232 to TCP/IP
- Powered by external 12 V wall adapter type power supply
- Enables Ethernet networking for AC-115 and AC-215, AC-225, or AC-425 panels
- Configurable using dedicated software utility or directly using AxTraxNG software, AYC-W6500 as well as intrusion alarm panels AuraSys and HomeLogiX.
MD-W11 Wireless Access Control Door Interface
SKU:
MD-W11
MAIN FEATURES
- Maximum range of 70 meters (230 ft) indoors and up to 300 meters (985 ft) outdoors with an external fixed antenna, depending on RF related environmental conditions
- Overall response time of 500 ms when used with Rosslare’s AC-225 controller and readers. Response time depends on RF link quality, the number of doors used, and the controller and reader’s response time.
- Built-in charger for up to 7 Ah backup battery on the remote unit
- Compatible with all of Rosslare’s readers and with many third-party standard Wiegand readers
- Separate sets of terminals for door and controller connections
- Case and wall tamper protection. Tamper events from either Near or Far sides are reported using a tamper output on the Near unit
- Transfers proximity card information as well as LED control, reader tamper, lock relay commands, and REX and Door Monitor events between the coupled units
- The Near unit is powered using the controller’s power supply. The Far unit is powered by a local wall transformer. A built-in charger provides a power backup option
- Protected housing with space for Rosslare’s BT- 04, 12 VDC 800 mAh, Sealed Lead-Acid battery. Suitable for Indoor use
- Available in HR-869 MHz and GR-433 MHz bands
ME-1515-U AC-825IP Series Controller Enclosure with Integrated Power Supply
SKU:
ME-1515-U
- Global input voltage-100 to 240 VAC, 1.6 A, 50/60Hz auto select.
- Power module delivers isolated 13.8 VDC power @ 2 Amp output channels with PTC resettable fuse and LED indications.
- Built-in power event generation to let the control panels receive power supply and UPS events.
- Built-in Rosslare LightBar for lighting the way during maintenance and installation.
- Full system hinge and key lock unit (including 2 keys), thick high-quality oven baked black matte coating.
- Silk screen of all the connections on inside of door.
- Rosslare PowerLock C13 socket – power cable can be secured using a locking mechanism and cannot be pulled out of the socket. Can be supplied with various C14 power plugs per country requirements.
- Supplied with removable terminal blocks and special key for ease of installation.
MW3222-V 22″ FHD LED Monitor for 24/7 Operation
SKU:
MW3222-V
NC214-XDZ 4 MP IR VF Network varifocal Turret Camera
SKU:
NC214-XDZ
Product Overview
The NC214-XDZ is a 4 MP IR varifocal turret camera designed for flexible high-definition surveillance. With 2560 × 1440 resolution, 120 dB WDR, and up to 30 m IR range, it provides clear imaging in various lighting conditions. Built-in analytics and smart monitoring features enhance situational awareness for indoor and outdoor environments.Key Features
- 4 MP High-Definition Imaging: Delivers detailed video with 2560 × 1440 resolution at 20 fps.
- Varifocal Lens Flexibility: Adjustable 2.8 mm to 12 mm lens allows precise field-of-view control.
- 120 dB Wide Dynamic Range: Ensures clear imaging in scenes with strong contrast and backlighting.
- IR Night Vision: Up to 30 m IR range for low-light and night-time monitoring.
- Smart Video Analytics: Supports region of interest, slow shutter, and built-in behavior detection for accurate event capture.
- Built-in Storage Support: Includes microSD/SDHC/SDXC slot up to 128 GB, plus local and NAS storage options.
- Flexible Installation: 3-axis adjustment (pan, tilt, rotate) allows precise camera positioning in multiple environments.
Key Specifications
- Image Sensor: 1/3" Progressive Scan CMOS
- Max. Resolution: 2560 × 1440
- Lens: 2.8–12 mm Varifocal, Φ14 mount
- Protection: IP67
- Power Supply: 12 VDC ±25% or PoE (802.3af, max. 12.5 W)
NC224G2-XD/LU 4 MP Smart Hybrid Light Turret Network Camera
SKU:
NC224G2-XD/LU
Product Overview
The NC224G2-XD/LU delivers clear and reliable surveillance with 2560 × 1440 high-resolution imaging. Featuring Smart Hybrid Light technology and human and vehicle detection, it enhances monitoring accuracy in various environments. With built-in audio recording, H.265+ compression, and IP67 weather protection, the camera provides efficient and dependable security performance.Key Features
- 4 MP High-Quality Imaging: Captures clear video with 2560 × 1440 resolution for detailed monitoring.
- Human & Vehicle Detection: Supports intelligent detection to identify human and vehicle targets for more focused security monitoring.
- Smart Hybrid Light Technology: Advanced lighting technology designed to provide long-range illumination for improved visibility in low-light environments.
- Built-in Microphone for Audio Security: Equipped with a built-in microphone to capture real-time audio alongside video footage.
- On-board Storage Support: Supports microSD card storage up to 512 GB (optional) for local video recording.
- Efficient H.265+ Compression: Reduces bandwidth and storage usage while maintaining video quality.
- Weather-Resistant Design: Rated IP67 for water and dust resistance, making it suitable for outdoor installations.
- Low-Light Performance: Minimum illumination of 0.005 Lux (Color) and 0 Lux with IR, enabling monitoring in very low-light conditions.
- Flexible Installation: Supports pan 0°–360°, tilt 0°–75°, and rotation 0°–360° for easier camera positioning.
NC228G2-XD-LUJ 8 MP Smart Hybrid Light Fixed Turret Network Camera
SKU:
NC228G2-XD-LUJ 2.8mm
Product Overview
The NC228G2-XD-LUJ is an 8 MP Smart Hybrid Light turret network camera delivering Ultra HD 4K video with excellent low-light performance. Equipped with human and vehicle detection, advanced Smart Hybrid Light, and built-in audio, it provides intelligent surveillance with clear imaging and reliable monitoring day and night.Key Features
- Ultra HD 4K Imaging: Captures fine details with 3840 × 2160 resolution for professional-grade security coverage.
- Smart Human & Vehicle Detection: Uses deep learning algorithms to accurately identify human and vehicle targets, reducing false alarms.
- Smart Hybrid Light Technology: Adaptive lighting delivers up to 30 m illumination, switching between infrared and white light for optimal visibility without overexposure.
- Enhanced Audio Security: Built-in microphone ensures synchronized audio recording alongside video for comprehensive evidence.
- Efficient H.265+ Compression: Optimizes bandwidth and storage while maintaining high-quality video streams.
- Low-Light Performance: Minimum illumination of 0.01 Lux in color mode and 0 Lux with IR ensures reliable monitoring in challenging lighting conditions.
- High WDR & Image Clarity: 120 dB WDR and SNR ≥ 52 dB provide sharp, clear images even in high-contrast scenes.
- Image Sensor: 1/2.7" Progressive Scan CMOS
- Max. Resolution: 3840 × 2160 (8 MP)
- Lens: 2.8 mm Fixed Lens, M12 Mount
- IR Range: Up to 30 m
- Protection: IP67
NC303-TD 3MP HD Fixed IR Dome Network Camera 4mm
SKU:
NC303-TD 4mm
Product Overview
The NC303-TD is a 3 MP HD fixed IR dome camera designed for reliable real-time surveillance. Featuring HD resolution, intelligent low-light performance, and onboard storage, it delivers clear, detailed video with night-time IR support and advanced image enhancements.Key Features
- High-Definition Imaging: Captures sharp video at 2048 × 1536 resolution for accurate monitoring.
- Advanced Low-Light Performance: Minimum illumination of 0.07 Lux in color mode and 0 Lux with IR ensures visibility in dark environments.
- Intelligent IR Night Vision: Infrared LEDs provide up to 30 m coverage, maintaining consistent night-time surveillance.
- Enhanced Image Processing: 3D DNR, Digital WDR, and BLC enhance clarity and reduce noise in challenging lighting conditions.
- Onboard and Network Storage: Supports microSD/SDHC/SDXC cards up to 64 GB and NAS storage for flexible video retention.
- Efficient Bandwidth Management: H.265/H.264 compression ensures smooth streaming with minimal storage usage.
- Robust Protection: IP66 rated housing delivers dust and water resistance for reliable outdoor performance.
Key Specifications
- Image Sensor: 1/3" Progressive Scan CMOS
- Max. Resolution: 2048 × 1536 (3 MP)
- Lens: 4 mm Fixed Lens, M12 Mount
- IR Range: Up to 30 m
- Power Supply: 12 VDC ±10% or PoE (802.3af, Max. 7 W)
NC304-VDZ 4MP Ture WDR Motorized focal IR Vandal Dome Network Camera
SKU:
NC304-VDZ
Product Overview
The NC304-VDZ is a 4 MP motorized dome camera offering high-resolution imaging with advanced WDR and intelligent IR illumination. With built-in storage, audio/alarm support, and robust vandal and weather protection, it delivers reliable and adaptive surveillance in diverse environments.Key Features
- 4 MP High-Resolution Imaging: Delivers sharp video at 2688 × 1520 for detailed monitoring.
- Motorized Varifocal Lens: Adjustable 2.8–12 mm lens allows flexible field-of-view control remotely.
- Smart IR Night Vision: Infrared LEDs provide up to 30 m illumination, ensuring consistent night-time visibility.
- Enhanced Image Processing: 120 dB WDR and 3D DNR maintain clarity in high-contrast and low-light conditions.
- Onboard and Network Storage: Supports microSD/SDHC/SDXC up to 128 GB and NAS storage for reliable video retention.
- Audio and Alarm Integration: Optional audio/alarm I/O (-S) enables synchronized event detection and recording.
- Robust Protection: IP66 weatherproof and IK10 vandal-resistant housing ensures durability in harsh environments.
Key Specifications
- Image Sensor: 1/3" Progressive Scan CMOS
- Max. Resolution: 2688 × 1520 (4 MP)
- Lens: Motorized 2.8–12 mm, Φ14 mount
- IR Range: Approx. 20–30 m
- Power Supply: 12 VDC ±10% or PoE (802.3af, Max 5.5 W)
NC304-WDA 4MP True WDR Network Mini Dome Camera Build in Mic- with Audio/alarm
SKU:
NC304-WDA 6mm
Product Overview
The NC304-WDA is a 4 MP mini dome camera delivering high-resolution video with True WDR and advanced noise reduction. Featuring built-in audio and alarm I/O, along with robust weather and vandal protection, it ensures reliable monitoring in both indoor and outdoor environments.Key Features
- 4 MP HD Imaging: Captures clear 2688 × 1520 video for detailed surveillance.
- True WDR & 3D DNR: Maintains image clarity under challenging lighting conditions.
- Fixed Lens Options: 2.8 mm or 4 mm lens for optimized field-of-view coverage.
- IR Night Vision: Provides up to 10 m infrared illumination for low-light monitoring.
- Integrated Audio & Alarm: Built-in microphone, audio output, and alarm I/O enable synchronized event recording.
- Dual Video Streams: Supports simultaneous main and sub-streams for flexible bandwidth management.
- Durable Design: IP66 weatherproof and IK08 vandal-resistant housing ensures long-term reliability.
Key Specifications
- Image Sensor: 1/3" Progressive Scan CMOS
- Max. Resolution: 2688 × 1520 (4 MP)
- Lens Size: 6 mm fixed, M12 mount
- Power Supply: DC12V ±10% or PoE (802.3af, Max 5 W)
- IR Range: Approx. 10 m
NC305-TD 5MP WDR Fixed IR Dome Network Camera
SKU:
NC305-TD 4mm
Product Overview
The NC305-TD is a 5 MP fixed dome camera delivering high-resolution video with digital WDR and 3D noise reduction. Equipped with advanced intrusion and line-crossing detection, it provides reliable monitoring day and night, backed by robust IP66-rated vandal-proof housing.Key Features
- 5 MP High-Resolution Imaging: Captures detailed 2560 × 1920 video for clear surveillance.
- Intelligent Motion Detection: Supports intrusion and line-crossing analytics for event-triggered alerts.
- Fixed Lens & 3-Axis Adjustment: 4 mm lens with flexible pan, tilt, and rotation for precise coverage.
- Infrared Night Vision: Up to 30 m IR illumination ensures clear images in low-light conditions.
- On-Board Storage Support: Optional microSD/SDHC/SDXC storage for local recording.
- Durable Design: Vandal-proof metal housing, IP66 weatherproof, built to withstand harsh environments.
- Dual Video Stream Support: Efficient bandwidth management with simultaneous main and sub-streams.
Key Specifications
- Image Sensor: 1/2.9" Progressive Scan CMOS
- Max. Resolution: 5 MP
- Lens Size: 4 mm fixed, M12 mount
- Power Supply: DC12V ±10% or PoE (802.3af, Max. 5 W)
- IR Range: 10–30 m
