W-VB202C Single channel passive video balun
SKU:
W-VB202C
W-VBCVI303E HD CCTV Via Twisted Pair
SKU:
W-VBCVI303E
Features:
- Compatible with all HD-CVI, HD-TVI, HD-AHD
- Up to 450m for 720P CVI Cameras
- Up to 250m for 1080P CVI Cameras
- Up to 250m for 720P & 1080P TVI Cameras
- Up to 320m for 720P AHD cameras
- NTSC, PAL and SECAM video formats
- no power required
- 60dB cross talk and noise immunity
- Compact size and easy installation
- Built-in transient suppression protection
- Innovative combinable design
Technical Specifications:
- Frequency response: DC to 60Mhz
- Attenuation: 0.5dB type
- CMRR: 60dB
- Surge protection: 4KV, ESD:8KV
- Connectors: Male BNC and terminal blocks
- Impendance:BNC 75ohms, Terminal: 100ohms
- Working Temperature: -10°C to +70°C
- Storage Temperature: -30°C to +70°C
- Humidity:0 to 95%
- Dimension 33m*17mm*16mm(excluding connectors)
- Material ABS Plastic
WAC348E-FD/FU 4K ColorVu POC Fixed Turret Camera
SKU:
WAC348E-FD/FU
Product Overview
The WAC348E-FD/FU is a 4K ColorVu fixed turret camera designed to deliver continuous full-color surveillance. Equipped with a 1/2.8" Sony CMOS sensor, the camera captures ultra-high-definition video up to 3840 × 2160 resolution. With advanced ColorVu technology and integrated white light illumination, it maintains vivid color images even during nighttime conditions. True WDR technology provides balanced exposure in high-contrast environments, ensuring clear details in both bright and dark areas of the scene. Image processing features such as 3D digital noise reduction further enhance clarity and reduce visual noise. The camera includes a 2.8mm fixed lens optimized for wide-area monitoring. With a durable IP67-rated housing, it is built to perform reliably in outdoor environments exposed to dust and water.
Key Features
- 4K Ultra HD Color Imaging: Captures highly detailed surveillance video at 3840 × 2160 resolution
- 24/7 Full-Color Monitoring: ColorVu technology with white light enables continuous color imaging day and night
- Enhanced Backlight Handling: 130 dB true WDR balances strong contrast scenes for clearer visibility
- Advanced Image Noise Reduction: 3D DNR improves clarity by minimizing noise in low-light conditions
- Bright Night Surveillance: White light illumination reaches up to 40 meters for improved night visibility
- Wide-Angle Monitoring: 2.8mm fixed lens provides stable and consistent scene coverage
- Rugged Outdoor Protection: IP67-rated metal housing protects against water and dust
- Image Sensor: 1/2.8" Sony CMOS sensor
- Max Resolution: 8MP (3840 × 2160)
- Lens: 2.8mm fixed lens
- Minimum Illumination: 0.01 lux (color), 0 lux with IR
- White Light Distance: Up to 40m
WNC2015-PIR 5MP HD pin-hole H.265/H.264 IP Camera
SKU:
WNC2015-PIR 3.7mm
Product Overview
The WNC2015-PIR is a 5MP pin-hole IP camera designed for discreet high-definition surveillance. Equipped with a 1/3" CMOS sensor, it delivers detailed video up to 2592 × 1944 resolution. The camera features ultra-low illumination capability, maintaining clear images even in dim lighting conditions. Integrated infrared LEDs provide night visibility up to 10–15 meters, ensuring continuous monitoring around the clock. Advanced imaging technologies including DWDR, 2D/3D-DNR, and automatic IR-CUT switching help maintain balanced and noise-reduced images in challenging lighting environments. Intelligent functions such as human detection and motion detection improve monitoring accuracy by focusing on meaningful events. With H.265/H.264 dual-stream compression, the camera optimizes bandwidth and storage efficiency. ONVIF compatibility, RTSP streaming, and P2P cloud access enable easy integration with NVR systems and remote viewing via web browsers, PC clients, or mobile applications.Key Features
- 5MP High-Definition Video Capture: Provides ultra-clear surveillance with up to 2592 × 1944 resolution, allowing users to capture fine image details and improve overall monitoring accuracy.
- Discreet Pin-Hole Surveillance Design: Compact pin-hole camera style enables unobtrusive monitoring, making it suitable for environments where low-profile surveillance is required.
- Intelligent Human & Motion Detection: Built-in detection functions help identify human activity and motion events, improving security monitoring efficiency and reducing unnecessary alerts.
- Enhanced Low-Light Performance: Ultra-low illumination sensitivity down to 0.01 Lux ensures clear image capture in dim environments, while IR LEDs provide night visibility up to 10–15 meters.
- Advanced Image Optimization Technologies: DWDR balances exposure in scenes with strong contrast, while 2D/3D digital noise reduction improves image clarity by minimizing noise in low-light conditions.
- Efficient H.265 / H.264 Dual-Stream Compression: Dual-stream encoding optimizes network bandwidth usage and storage efficiency while maintaining high-quality video transmission.
- Flexible Network & Remote Access Support: ONVIF and RTSP compatibility allow seamless integration with third-party NVRs, while P2P cloud service enables remote monitoring via web browsers, PC software, and mobile applications.
- Image Sensor: 1/3" CMOS
- Max Resolution: 2592 × 1944 (5MP)
- Lens: 3.7mm HD pin-hole lens
- Night Vision: 12 IR LEDs, IR distance 10–15 m
- Power Supply: 12V DC ±10%, power consumption <5W
WNC2016-EV 6MP HD Elevator fixed IP Camera
SKU:
WNC2016-EV 2.8MM
Product Overview
The WNC2016-EV is a 6MP HD fixed IP camera specially designed for elevator surveillance. Featuring a 1/2.8" Sony CMOS sensor, it delivers real-time 3072 × 2048 resolution for crisp and detailed images. Its ultra-low light sensitivity of 0.01 Lux ensures visibility in dim conditions, while the integrated IR LED provides night monitoring up to 5–6 meters. Advanced imaging technologies, including DWDR, 2D/3D-DNR, BLC, and HLC, maintain clarity under challenging lighting conditions such as strong backlight or glare. Intelligent detection functions, including human and vehicle recognition, enhance monitoring accuracy. The camera supports H.265/H.264 dual-stream encoding, ONVIF/RTSP protocols, and P2P cloud access for flexible integration with NVR systems and remote monitoring via web browsers, PC client, and mobile applications. Designed with IP66 protection and lightning resistance, the WNC2016-EV is optimized for the confined, high-traffic environment of elevators.Key Features
- 6MP Ultra HD Imaging: Captures high-resolution 3072 × 2048 video to provide detailed surveillance in small elevator spaces
- Compact Elevator-Optimized Design: Fixed turret form factor fits easily in elevator interiors without obstructing movement
- Intelligent Human & Vehicle Detection: Automatically identifies people and vehicles to reduce false alarms and focus on real security events
- Advanced Low-Light Performance: 0.01 Lux sensitivity combined with a built-in IR LED ensures clear images even in near-dark conditions
- Image Enhancement Technologies: DWDR balances strong backlight; 2D/3D-DNR reduces noise; BLC/HLC improve clarity under complex lighting
- Flexible Network Integration: Supports H.265/H.264 dual-stream, ONVIF 17.06, RTSP, P2P cloud, and multiple browser access for easy monitoring and recording
- Reliable Outdoor & Indoor Protection: IP66-rated housing with lightning protection ensures stable operation in confined and challenging environments
- Image Sensor: 1/2.8" Sony CMOS
- Max Resolution: 3072 × 2048 (6MP)
- Lens: 2.8mm fixed lens
- Night Vision: 1 IR LED, range 5–6 meters
- Power Supply: 12V DC ±10%, power consumption <8W
WNC4018-XDSLU 4K full color Two-way Audio Turret IP Camera
SKU:
WNC4018-XDSLU
Product Overview
The WNC4018-XDSLU is a 4K full-color turret network camera designed for high-definition and intelligent surveillance. Powered by a 1/2.8" Sony CMOS sensor, it captures ultra-clear 3840 × 2160 video with excellent detail. With warm light illumination and F1.0 aperture lens, the camera maintains vivid color images even in low-light environments. Advanced image processing technologies including D-WDR, 2D/3D-DNR, BLC, and HLC help deliver balanced and noise-reduced images in complex lighting conditions. The camera supports intelligent human and vehicle detection, improving monitoring efficiency by focusing on meaningful events. Integrated two-way audio enables direct communication through the camera. With ONVIF compatibility, RTSP streaming, and dual-stream H.265/H.264 compression, the device integrates easily with many NVR platforms. Its IP66 weatherproof housing and PoE support ensure reliable deployment in outdoor security applications.Key Features
- 4K Ultra HD Imaging: Captures ultra-detailed 3840 × 2160 video for high-precision monitoring
- Full-Color Night Monitoring: Warm light illumination enables color images in low-light scenes
- Intelligent Target Detection: Supports human and vehicle detection for more focused security alerts
- Two-Way Audio Communication: Built-in microphone and speaker enable remote interaction
- Advanced Image Enhancement: D-WDR, 3D-DNR, BLC and HLC optimize image clarity in challenging lighting
- Flexible Network Integration: ONVIF and RTSP support allows compatibility with many third-party NVRs
- Secure Remote Access: P2P cloud service, encrypted data transmission, and multi-platform access
- Image Sensor: 1/2.8" Sony CMOS
- Max Resolution: 3840 × 2160 (4K)
- Lens: 2.8mm F1.0 HD lens
- Night Lighting: 2 warm lights, illumination distance 20–30m
- Network & Power: RJ45 100Mbps, IEEE802.3af PoE support
