Image Sensor	1/1.8″ Progressive Scan CMOS
Camera Resolutions	4 MP
Camera Style	Bullet
Lens Type	Fixed Lens
Lens Size	2.8mm
Angle Adjustment	Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Behavior Analysis	Line crossing detection, intrusion detection, object removal detection, unattended baggage detection
Communication Interface	1 RJ45 10M/100M self-adaptive Ethernet port
Compression	Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
Day & Night	Day/Night
Digital Noise Reduction	3D DNR
Electronic Shutter Speed	1/3 s to 1/100, 000 s
Exception Detections	Scene change detection
Face Detection	Yes
Focal Length	4mm
Focus Control	Fixed
FOV	4 mm, horizontal FOV: 94°, vertical FOV: 48°, diagonal FOV: 115°
General Function	One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Image Enhancement	BLC/3D DNR/HLC
Image Settings	Rotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
Lens Mount	M16
Material	Front cover: metal, back cover: metal
Max Aperture	F1.0
Max. Resolution	2688 × 1520
Min. Illumination	0.0014 @ (F1.0, AGC ON), 0 Lux with Light
Network Storage	Support micro SD/SDHC/SDXC card (128G) local storage, NAS (NFS, SMB/CIFS), ANR
Wide Dynamic Range	120dB
On-Board Storage	Built-in micro SD/SDHC/SDXC slot, up to 128 GB
Power Supply	12 VDC ± 25%, 5.5 mm coaxial power plug PoE (802.3af, class 3)
Power Consumption	12 VDC, 0.7 A, max. 9.5 W PoE: (802.3af, 36 V to 57 V), 0.3 A to 0.1 A, max. 11 W
Video Bit Rate	32 Kbps to 16 Mbps
Protection	IP67
Weight	Camera: 1200 g (2.6 lb.) With package: 1800 g (4 lb.)
Dimensions	Camera: Φ 105 × 290.7 mm (Φ 4.1″ × 11.4″) With package: 385 × 190 × 180 mm (15.2″ × 7.5″ × 7.1″)

Image Sensor	1/3″ProgressiveScanCMOS
Camera Resolutions	4 MP
Camera Style	Turret
Lens Size	2.8mm
Lens Type	Fixed Lens
Min.Illumination	Color:0.001Lux@(F1.0, AGCON), 0Luxwithlight
Shutter Speed	1/12sto1/100, 000s
Aperture	F1.0
Day & Night	IR cut filter
Lens Mount	M12
Video Bit Rate	256 Kbps to 8 Mbps
Angle Adjustment	Pan: 0°to 360°, tilt: 0°to 75°, rotate: 0°to 360°
IR Range	Up to 30 m
Wavelength	850nm
Audio	Built-in Two-Way Audio
Communication Interface	1RJ45 10M/100M self-adaptive Ethernet port
Power Supply	12V DC±25%, 0.75A, max.9W, Ø5.5mm coaxial power plug, reverse polarity protection, PoE:IEEE802.3af, Class3, max.10.5W
General Function	Heartbeat, mirror, flashlog, password reset via email, pixel counter, anti-banding
Protection	IP67
Material	Cover: metal, mainbody: metal
Dimensions	Ø138.3mm×115.4mm(Ø5.4″×4.5″)
Weight	Approx.820g(1.8lb.)

Image Sensor	2 × 1/1.8″ Progressive Scan CMOS
Camera Resolutions	8 MP
Camera Style	Turret
Lens Type	Fixed Lens
Lens Size	4mm
Angle Adjustment	Pan: -30° to 30°, tilt: -75° to 75°
Audio Type	Mono sound
Day & Night	Day, Night, Auto, Schedule
DORI Distance	4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m
Focal Length	Horizontal FOV: 180° ± 10° Vertical FOV: 44°
Image Enhancement	BLC, HLC, 3D DNR
Image Parameters Switch	Yes
Image Settings	saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
Lens Mount	M16
Main Stream	When WDR is On: 50 Hz: 12.5 fps (5120 × 1440) 60 Hz: 15 fps (5120 × 1440) When WDR is Off: 50 Hz: 20 fps (5120 × 1440) 60 Hz: 20 fps (5120 × 1440)
Material	Base: metal, cover: metal
Max Aperture	F1.0
Max. Resolution	5120 × 1440
Min. Illumination	Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light
On-Board Storage	Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 256 GB
Power	12 VDC ± 25%, 0.79 A, max. 9.5 W, Ø5.5 mm coaxial power plug, PoE: 802.3af, Class 3, 36 V to 57 V, 0.29 A to 0.18 A, max. 10.5 W
Premier Protection	Line crossing, intrusion, region entrance, region exiting (support alarm triggering by specified target types (human and vehicle))
Shutter Time	1/3 s to 1/100, 000 s
Supplement Light Range	Up to 30 m
Supplement Light Type	White Light
Video Bit Rate	32 Kbps to 16 Mbps
Dimensions	Ø155 mm × 155.3 mm (Ø6.1″ × 6.1″)
Weight	Approx. 1110 g (2.4 lb.)
Protection	IP67: IEC 60529-2013
Wide Dynamic Range	130 dB

Audio	Built-in Microphone
Electronic Shutter Speed	1 s to 1/100, 000 s
Camera Style	Turret
Lens Type	Fixed Lens
Horizontal Field of View	2.8 mm, horizontal FOV 108.8°, vertical FOV 56.4°, diagonal FOV 134.3°
Image Sensor	1/1.8” progressive scan CMOS
IR On/Off Control	Yes
IR Range	Up to 30 m
Lens Size	2.8mm
Lens Mount	M16
Min. Illumination	Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light
Camera Resolutions	8 MP
Signal System	PAL/NTSC
Smart IR	Yes
Smart Supplement Light	Yes
Supplement Light Range	Up to 30 m
Supplement Light Type	White Light, IR
Color	White

Camera Resolutions	2 MP
Camera Style	Bullet
Lens Type	Varifocal Lens
Lens Size	8-32mm
Image Sensor	1/1.8″ Progressive Scan CMOS
Max. Resolution	1920 × 1080
Min. Illumination	Color: 0.0005 Lux @ (F1.2, AGC ON); B/W: 0.0001 Lux @ (F1.2, AGC ON)，0 Lux with IR
Shutter Time	1 s to 1/100, 000 s
Day & Night	IR cut filter Blue glass module to reduce ghost phenomenon
Wavelength	850 nm
Video Bit Rate	32 Kbps to 8 Mbps
WDR	140 dB
SNR	≥ 52 dB
Power	12 VDC ± 20%, 1.19 A, max. 14.28 W, three-core terminal block PoE: 802.3at, Type 2, Class 4, 42.5 V to 57 V), 0.396 A to 0. 295 A, max. 16.8 W
Material	Aluminum alloy body
Dimension	Ø144 × 347 mm (Ø5.7″ × 13.7″)
Package Dimension	405 × 190 × 180 mm (15.9″ × 7.5″ × 7.1″)
Weight	Approx. 1950 g (4.2 lb.)
With Package Weight	Approx. 3070 g (6.7 lb.)
Protection	IK10, IP67

Image Sensor	Varifocal: 1/2.4″ Progressive Scan CMOS; Fixed: 1/2.5″ Progressive Scan CMOS
Max. Resolution	2560 × 1920
Min. Illumination	Color: 0.005 Lux @ (F1.2, AGC ON),B/W: 0.002 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR
Shutter Time	1 s to 1/100,000 s
Day & Night	IR cut filter
Angle Adjustment	Pan: 0° to 350°,tilt: 0° to 90°,rotate: -90° to 90°
Lens Type Focal Length & FOV	Varifocal :2.8 to 8 mm, horizontal FOV 96.5° to 48.9°, vertical FOV 69.9° to 36.5°, diagonal FOV 129° to 61.3° Fixed:2mm, horizontal FOV 71.68°, vertical FOV 71.68°, diagonal FOV 99.16°
Focus	Varifocal: Semi-auto,Manual
Aperture	Varifocal: F1.9; Fixed: F2.25
Supplement Light Type	IR
Supplement Light Range	Up to 30 m
IR Wavelength	850 nm
Video Main Stream	Channel 1,2,3,4: 60 Hz: 30 fps (2560× 1920, 2048× 1536, 1920 × 1080, 1280 × 720) Channel 5: 60 Hz: 30 fps (1440× 1440)
Sub-Stream	Channel 1,2,3,4: 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) Channel 5: 50 Hz: 25 fps (576× 576, 480× 480) 60 Hz: 30 fps (576× 576, 480× 480)
Third Stream	Channel 1,2,3,4: 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
Video Compression	Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264
Video Bit Rate	32 Kbps to 8 Mbps
H.264 Type	Baseline Profile,Main Profile,High Profile
H.265 Type	Main Profile
Audio Compression	G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate	64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate	8 kHz/16 kHz/32 kHz/48 kHz
Environment Noise Filtering	Yes
Protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, WebSocket, WebSockets, SSL/TLS
Simultaneous Live View	Up to 20 channels
Security	Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface
Image Settings	Rotate mode,saturation,brightness,contrast,sharpness,AGC,white balance,adjustable by client software or web browser
Wide Dynamic Range (WDR)	120 dB
Image Stabilization	EIS
Image Enhancement	BLC,HLC,3D DNR,Defog
Ethernet Interface	1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
On-Board Storage	Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB
Audio	1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Alarm	2 inputs, 2 outputs (max. 24 VDC, 1 A)
RS-485	1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Reset Key	Yes
Perimeter Protection	Line crossing, intrusion, region entrance, region exiting Support alarm triggering by specified target types (human and vehicle)
Power	12 VDC ± 20%, 1.8 A, max. 21.6 W, PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.58 A to 0.43 A, max. 25 W
Dimension	Product Ø 290 mm × 148 mm (Ø 11.42″ × 5.8″) Package Dimension 453 mm × 393 mm × 385 mm (17.8″ × 15.47″ × 15.16″)
Weight	Product Weight Approx. 4.7 kg (10.36 lb.) With Package Weight Approx. 8.0 kg (17.63 lb.)

Camera Resolutions	6 MP
Camera Style	Fisheye
Audio	Built-in Microphone, Built-in Speaker
Alarm Trigger	Motion detection, video tampering alarm, network disconnected, IP address conflicted, illegal login, HDD full, HDD error
Audio Bit Rate	64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32‐160Kbps(MP2L2)
Audio Interface	2 built‐in microphones, 1 built‐in speaker, mono sound 1 Audio input (line in, 3.5 mm), 1 audio output (line out, 3.5 mm)
Audio Sampling Rate	8 kHz/16 kHz
Communication Interface	1 RJ45 10M/100M/1000M self‐adaptive Ethernet port
Compression (audio)	G.711/G.722.1/G.726/MP2L2/PCM
Color	White
Day & Night	Day/Night/Auto/Schedule/Triggered by Alarm In
Digital Noise Reduction	3D DNR
Dimensions	167.4 × 152.8 × 55 mm (6. 6″ × 6″ × 2.2″)
Electronic Shutter Speed	1 s to 1/100, 000 s
Environment Noise Filtering	Yes
Exception Detections	Audio exception detection
Focal Length	1.27 mm
Image Enhancement	BLC, HLC, defog, 3D DNR
Image Settings	Saturation, brightness, contrast, sharpness, AGC and white balance are adjustable by client software or web browser
Intersection Analysis	Detects and analyze flow in an intersection‐like scene, and generate reports Support one intersection of up to 10 ways
Lens Mount	M12
Material	Metal
Max Aperture	F2.6
Min. Illumination	Color: 0.047 Lux @ (F2.6, AGC ON), B/W: 0.0047 Lux @ (F2.6, AGC ON), 0 Lux with IR
Mount Type	Support table, wall, and ceiling mounting
Network Storage	Support microSD/SDHC/SDXC card (256 G), local storage and NAS (NFS, SMB/CIFS), ANR
On-Board Storage	Built‐in micro SD/SDHC/SDXC slot, up to 256 GB
Operating Conditions	‐40 °C to +60 °C (‐40 °F to +140 °F), Humidity 95% or less (non‐condensing)
People Counting	Counts people entering, exiting and passing by separately Supports real‐time uploading and uploading by statistic cycle Sends email reports on daily, weekly, monthly or annually basis Supports target filtering by height
Power Consumption	12 VDC, 1 A, max. 12.5 W PoE (802.3at, 42.5 to 57 V), 0.4 A to 0.3 A, max. 15 W
Power Supply	12 VDC±20%, PoE (802.3at, class 4), two‐core terminal block
Protocol	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
Reset Button	Yes
Resolution	3072 × 2048
Simultaneous Live View	Up to 20 channels
Slow Shutter	Yes
Wavelength	850 nm
Weight	Approx. 1400 g (3.09 lbs)
Wide Dynamic Range	Digital WDR
Protection	IP67, IK08

Image Sensor	1/1.7″ Progressive Scan CMOS
Audio	Built-in Microphone, Built-in Speaker
Minimum Illumination	Color: 0.05 Lux@(F2.2, AGC ON), B/W: 0.01 Lux@(F2.2, AGC ON), 0 Lux with IR
Shutter Speed	1 s to 1/100, 000 s
WDR	DWDR
Focal length	1.29mm
Lens Mount	M12
IR Range	Up to 15 m
Wavelength	850nm
Video Compression	Main stream: H.265+/H.265/H.264+/H.264 Sub stream: H.265/H.264/MJPEG
Video Bit Rate	32 Kbps to 16 Mbps
Power	12 VDC±20%, PoE(802.3at, class 4), two‐core terminal block
Power Consumption and Current	12 VDC, 1 A, max. 12.5 Ws PoE (802.3at, 42.5 to 57 V), 0.4 A to 0.3 A, max. 15 W
Camera Material	Metal
Package Dimension	167 x 152.8 x 55 mm(6. 6″x 6″ x 2.2″)
With Package Weight	Approx. 1400 g (3.09 lbs)
